ABS injection mold

We specialize in custom ABS injection mold development, ABS plastic component production, and optional assembly services—not finished product trading. Our molds are engineered to maximize the performance of ABS (Acrylonitrile Butadiene Styrene) , with tailored structures optimized for ABS’s flowability, rigidity, and surface finish, delivering high-quality ABS parts for electronics, home appliances, automotive interiors, and consumer goods.

1. Custom Mold Structures: Tailored to ABS’s Molding Characteristics

ABS’s balanced properties (good flow, moderate shrinkage, high rigidity)

Our custom mold structures address these needs:

Cavity & Core: Machined via high-precision CNC machining (tolerance as tight as ±0.02mm) to leverage ABS’s excellent detail reproduction. Features include:

Smooth surface finishes (Ra ≤0.4μm) to replicate high-gloss or textured ABS parts (e.g., phone casings, appliance panels).

Reinforcement rib design (thickness 1/3–1/2 of base wall, spaced 2–3× wall height) to prevent sink marks—critical for ABS’s moderate shrinkage (1.5–2.5%).

Draft angles (1–3° for vertical surfaces) to ensure easy demolding, as ABS’s rigidity can cause sticking if angles are insufficient.

Gating System: Optimized for ABS’s flow behavior (medium melt viscosity). Options include:

Edge gates (for small-to-medium parts, e.g., electronic connectors) to minimize weld lines—ABS’s butadiene component can weaken welds if flow paths are uneven.

Hot runner systems (for large or multi-cavity parts, e.g., automotive interior trims) to maintain consistent melt temperature, reducing material waste by 15–20% and ensuring uniform part density.

Cooling System: Designed to control ABS’s cooling rate (critical for dimensional stability). Key features:

Uniform cooling channels (spaced 8–12mm apart) to avoid uneven shrinkage—prevents warping in large ABS parts (e.g., TV back panels).

Targeted cooling for thickened areas (e.g., boss structures) to reduce cycle time by 25–30%—ABS’s heat conductivity (0.19 W/m·K) requires efficient heat dissipation to avoid extended cooling.

Ejection System: Calibrated for ABS’s rigidity to prevent part damage:

Ejector pins (arranged at non-visible areas) with rounded tips to avoid marking ABS’s hard surface.

Stripper plates (for large flat parts) to distribute ejection force evenly—prevents cracking of rigid ABS components.

2. ABS Material Variants & Their Applications

ABS is available in modified grades to suit specific needs—we select the right ABS variant based on your component’s function and environment:

General-Purpose ABS (GP-ABS): Ideal for consumer goods (e.g., toy parts, household appliance housings). Offers balanced impact resistance (10–15 kJ/m²), rigidity (Shore D 75–80), and cost-effectiveness—suitable for low-to-medium stress applications.

High-Impact ABS (HI-ABS): Used for durable parts (e.g., laptop casings, tool handles). Modified with extra butadiene to boost impact resistance (20–30 kJ/m²)—withstands drops and shocks without breaking, ideal for portable devices.

Flame-Retardant ABS (FR-ABS): Perfect for electronic components (e.g., PCB enclosures, power supply housings). Meets UL94 V-0 standards—prevents flame spread in electrical applications, maintaining structural integrity at high temperatures (up to 100°C).

Glass-Filled ABS (GF-ABS, 10–30% GF): Great for structural parts (e.g., automotive interior brackets, industrial machine components). Reinforced with glass fiber to enhance tensile strength (up to 60 MPa) and reduce shrinkage (1.0–1.5%)—suitable for load-bearing ABS parts requiring dimensional precision.

High-Gloss ABS: Suitable for aesthetic parts (e.g., cosmetic packaging, audio device panels). Features a polished surface finish (no post-processing needed)—leverages ABS’s ability to retain high gloss, ideal for consumer goods where appearance is critical.

3. ABS Injection Molding Process: Optimized for Performance

Our injection process is fine-tuned to maximize ABS’s properties, with key advantages:

Precision & Consistency:

Melt temperature control (220–260°C) to ensure ABS flows evenly—avoids cold slugs or burn marks.

Injection pressure (70–100 MPa) calibrated for ABS’s viscosity—ensures full cavity filling without excessive stress (which can cause part warping).

Dimensional tolerance control (±0.03mm for small parts) via servo-driven machines—critical for ABS components requiring tight fits (e.g., electronic connectors).

Surface Quality:

Mold cavity polishing (Ra ≤0.2μm for high-gloss parts) to eliminate defects—ABS’s excellent surface reproduction ensures no visible blemishes.

Weld line reduction (via gate placement and melt temperature optimization)—improves strength and appearance of ABS parts with complex geometries.

Efficiency:

Cycle time optimization (20–40 seconds per part) via targeted cooling—balances production speed with ABS’s cooling requirements.

Multi-cavity molds (8–32 cavities for small parts, e.g., buttons) to boost output—ABS’s good flow supports uniform filling across multiple cavities, with daily production up to 50,000 parts for standard designs.

Cost-Effectiveness:

Hot runner systems reduce material waste (15–20%)—minimizes scrap from cold runners, lowering per-unit costs for high-volume ABS parts.

Integrated molding of features (e.g., ribs, bosses) eliminates post-processing—cuts labor costs and ensures consistent quality.

4. Our Services: Beyond Molds—ABS Components & Assembly

We provide end-to-end solutions for ABS production, tailored to your needs:

ABS Component Manufacturing: Produce custom ABS parts in sizes (5×5mm to 500×300mm), shapes (complex geometries, thin walls down to 0.8mm), and finishes (glossy, matte, textured). Supports color matching (RAL/Pantone codes) and post-processing (painting, plating, printing) to enhance ABS’s aesthetic appeal.

Value-Added Assembly: Optional assembly services for ABS sub-assemblies—such as attaching metal inserts (for strength), bonding ABS parts with adhesives, or integrating non-ABS components (e.g., rubber gaskets, electronic modules). Delivers ready-to-integrate sub-assemblies, saving your production time.

Custom Design Support: Offer 3D mold design and ABS prototyping (via CNC machining or injection molding). We produce 10–50 prototype parts in 3–5 days to test ABS’s performance (impact resistance, fit) and optimize the mold design before mass production.

We are plastic mold maker and can provide custom mold service, we can make injection molds, blow molds, rotational molds and die-casting molds.

For custom injection molds, we can provide professional custom injection molding services. Usually Plastic injection mold manufacturing Molding are manufactured using injection molding technology. The mold materials for injection molds can be chosen from P20, 718, S136, H13 and so on. The mold material reflects the mold life and product material requirements.

For parts that require blow molding production, we can also provide professional custom blow molding services.

Plastic injection mold manufacturing Injection Mould making

1.We communicate product design according to samples/drawings and your requirements.

2.After the product design is confirmed, we carry out the mold design, we provide all kinds of injection molds, blow molds, silicone molds, die-casting molds services.

3.Material procurement, steel cutting and mold basic tools.

4.Mold assembly

5.Mold inspection, tracking and controlling mold processing.

6. We will inform you the date of mold trial and send you the sample inspection report and injection parameters together with the sample.

7.Your instruction and confirmation of shipment.

8.Prepare the mold before packing.

Plastic injection mold manufacturing molding Specification

1. Professional manufacturer, design, production injection mould and stamping mould quality control

2. rich export experience plastic injection mould and stamping mould

3. Reasonable price of design mould

4. Cavities: single or as per your requirements cavity

5. Treatment: S45C Pretreat>25Hrc,And Nitriding

6. Mould Steel: Cavity ,Core and slide: P20 ,2738,2136 available Moldbase :LKM available

7. Standard:DEM ,HUSKY,available

8. Hot runner: according to your demand

9. Life time: >300 Thousand Times

10. Package: Plywood case, anti-rust paint

Mold design：

Information you need to provide us

1. If you have drawings, 2D drawings, 3D drawings (preferably in STEP format).

2. If there are no drawings, you need to provide specific length, width, height and weight information. (It’s best to send us samples)

3. Should the mold be sent to your country, or leave the mold in our factory and we will help you produce the product.

4. Mold material requirements, cavity number requirements (you can tell us about the size of your injection molding machine)

5. Product material requirements and product quantity. (You can tell us about the use of the product and we can give you suggestions)

Transaction process:

Mold testing：

Once the mold is complete, I do a mold test. It usually takes about 3-5 days to complete. We need to assemble the mold, adjust the pressure data of the machine, and try production. We need to check whether there are problems during the normal production of the mold and make modifications.

Product packaging

Packaging according to your needs

1.By air ,it takes 3-7 days for delivery .The goods can be shipped by DHL ,Fedex ,UPS .

2.By sea ,the delivery time is based on your port .

To South East Asian Countries takes about 5-12 days

To Middle east countries takes about 18-25 days

To European countries takes about 20-28 days

To American countries takes about 28-35 days

To Australia takes about 10-15 days

To African countries takes about 30-35 days.

Factory

Video-1: (Factory Video)

Video-2: (Injection Molding)

Video-3: (Blow molding)

Video-4: (Blow molding)

Video-5: (Roll molding)

Customer satisfaction is our most important goal. We focus on communication and cooperation with our customers, always pay attention to their needs and provide quick response and quality customer service. Our injection production mold factory is committed to establishing long-term relationships and ensuring that our customers receive the best after-sales service during the purchase and use of our products, and we will definitely do our best to solve any problems for our customers.

FAQ

1. Who are we?

We are based in Zhejiang, China, start from 2014,sell to North America(30.00%),Southern Europe(10.00%),Northern.

Europe(10.00%),Central America(10.00%),Western Europe(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%). There are total about 51-100 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment.

3. What can you buy from us?

Mould,Plastic Product, Metal Product,Dental Product,CNC machining.

4. Why should you buy from us not from other suppliers?

Ningbo P&M Plastic Metal Product Co., Ltd. We main do all kinds of 3d design, 3d printing and plastic metal molds tooling and products. We have our own engineer and factory. One-stop supply:3d design - 3d printing - mold making - plastic injection.

5. What services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU;

Accepted Payment Currency:USD,EUR;

Accepted Payment Type: T/T,L/C,PayPal,Western Union,Escrow;

Language Spoken:English,Chinese,Spanish,French,Russian.

6. What are the characteristics of your service?

1. Your inquiry related to our products or prices will be replied within 24hours.

2. Welltrained and experienced staffs to answer all your enquiries in fluent English.

3. Offering the support to solve the problem in the application or selling period.

4. Competitive prices based on same quality.

5. Guarantee samples quality same as mass production quality.
