plastic pet flight case part Molding

We specialize in manufacturing high-performance plastic components for pet flight cases through advanced injection molding technologies. Whether you need structural panels, ventilation grids, locking mechanisms, or pre-assembled sub-systems, our expertise in material science and high-volume production.

Key Flight Case Structures & Customization Options

1. Structural Shell & Panels

Design Flexibility:

Modular Panels: 300–1000mm dimensions with interlocking tongue-and-groove edges (tolerance ±0.2mm).

Impact Resistance: Ribbed reinforcement (3–6mm wall thickness) for 9G drop test compliance.

Weight Optimization: Honeycomb core structures (0.8–1.2g/cm³) for IATA-compliant tare weight.

Material Options:

PC/ABS Alloy: High impact strength (≥60kJ/m²) with flame retardancy (UL94 V-0).

Long-Fiber PP (LFT-PP): 40% weight reduction vs. aluminum, corrosion-resistant.

Carbon Fiber-Reinforced Nylon (PA-CF): Aerospace-grade stiffness for extreme conditions.

2. Ventilation & Airflow System

Functional Customization:

Laser-Cut Grids: 8–15mm hexagonal/polygonal vents .

Sliding Dampers: Adjustable airflow control for temperature-sensitive breeds.

HEPA Filter Slots: Snap-in frames (ISO 16890 compliant) for cabin air recirculation.

Material Precision:

UV-Stabilized ASA: Fade-resistant (10+ years outdoor use) with 90% UV blocking.

Antimicrobial PC: Silver-ion additive (to inhibit pathogen growth.

3. Locking & Security Mechanisms

Safety Features:

Tamper-Proof Hinges: Overmolded stainless steel pins with 50,000-cycle durability.

Pressure Relief Valves: Automatic opening at 2–5kPa for cabin altitude changes.

Material Choices:

POM (Acetal): Low friction for smooth sliding bolts.

Glass-Filled PBT: Heat-resistant (150°C) for cargo hold environments.

4. Interior & Accessories

Pet Comfort Enhancements:

Removable Trays: Co-injected PP/TPE surfaces with anti-slip textures (Ra 30–80μm).

Noise-Dampening Liners: Microcellular PU foam bonded to ABS panels (NRC 0.7+).

Water Dispenser Mounts: Leak-proof sockets with FDA-grade silicone seals.

Material Selection Guide

1. PC/ABS Alloy

Key Benefits:

Impact resistance , flame retardant, and UV stable.

Ideal for cabin-approved pet carriers .

Applications:

Main structural shell, cargo hold containers.

2. Long-Fiber Thermoplastics

Key Benefits:

30% lighter than standard polymers, vibration damping for turbulence.

Recyclable for sustainable aviation initiatives.

Applications:

Modular panel systems, lightweight frame components.

Advanced Injection Molding Capabilities

1. Precision Mold Design

Tooling Expertise:

Multi-cavity molds (up to 32 cavities) for large panels (1.5m²) with ±0.1mm/m flatness.

Conformal cooling channels to eliminate warpage in thick-walled structures.

Quick-change inserts for multi-model compatibility (e.g., dog vs. cat carriers).

Prototyping:

CNC-machined prototypes in 5 days

We are plastic mold maker and can provide custom mold service, we can make injection molds, blow molds, rotational molds and die-casting molds.

For custom injection molds, we can provide professional custom injection molding services. Usually Plastic pet flight case part  Molding are manufactured using injection molding technology. The mold materials for injection molds can be chosen from P20, 718, S136, H13 and so on. The mold material reflects the mold life and product material requirements.

For parts that require blow molding production, we can also provide professional custom blow molding services.

Plastic Plastic pet flight case part  Injection Mould making

1.We communicate product design according to samples/drawings and your requirements.

2.After the product design is confirmed, we carry out the mold design, we provide all kinds of injection molds, blow molds, silicone molds, die-casting molds services.

3.Material procurement, steel cutting and mold basic tools.

4.Mold assembly

5.Mold inspection, tracking and controlling mold processing.

6. We will inform you the date of mold trial and send you the sample inspection report and injection parameters together with the sample.

7.Your instruction and confirmation of shipment.

8.Prepare the mold before packing.

Plastic Plastic pet flight case part  molding Specification

1. Professional manufacturer, design, production injection mould and stamping mould quality control

2. rich export experience plastic injection mould and stamping mould

3. Reasonable price of design mould

4. Cavities: single or as per your requirements cavity

5. Treatment: S45C Pretreat>25Hrc,And Nitriding

6. Mould Steel: Cavity ,Core and slide: P20 ,2738,2136 available Moldbase :LKM available

7. Standard:DEM ,HUSKY,available

8. Hot runner: according to your demand

9. Life time: >300 Thousand Times

10. Package: Plywood case, anti-rust paint

Mold design：

Information you need to provide us

1. If you have drawings, 2D drawings, 3D drawings (preferably in STEP format).

2. If there are no drawings, you need to provide specific length, width, height and weight information. (It’s best to send us samples)

3. Should the mold be sent to your country, or leave the mold in our factory and we will help you produce the product.

4. Mold material requirements, cavity number requirements (you can tell us about the size of your injection molding machine)

5. Product material requirements and product quantity. (You can tell us about the use of the product and we can give you suggestions)

Transaction process:

Mold testing：

Once the mold is complete, I do a mold test. It usually takes about 3-5 days to complete. We need to assemble the mold, adjust the pressure data of the machine, and try production. We need to check whether there are problems during the normal production of the mold and make modifications.

Product packaging

Packaging according to your needs

1.By air ,it takes 3-7 days for delivery .The goods can be shipped by DHL ,Fedex ,UPS .

2.By sea ,the delivery time is based on your port .

To South East Asian Countries takes about 5-12 days

To Middle east countries takes about 18-25 days

To European countries takes about 20-28 days

To American countries takes about 28-35 days

To Australia takes about 10-15 days

To African countries takes about 30-35 days.

Factory

Video-1: (Factory Video)

Video-2: (Injection Molding)

Video-3: (Blow molding)

Video-4: (Blow molding)

Video-5: (Roll molding)

Customer satisfaction is our most important goal. We focus on communication and cooperation with our customers, always pay attention to their needs and provide quick response and quality customer service. Our injection production mold factory is committed to establishing long-term relationships and ensuring that our customers receive the best after-sales service during the purchase and use of our products, and we will definitely do our best to solve any problems for our customers.

FAQ

1. Who are we?

We are based in Zhejiang, China, start from 2014,sell to North America(30.00%),Southern Europe(10.00%),Northern.

Europe(10.00%),Central America(10.00%),Western Europe(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%). There are total about 51-100 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment.

3. What can you buy from us?

Mould,Plastic Product, Metal Product,Dental Product,CNC machining.

4. Why should you buy from us not from other suppliers?

Ningbo P&M Plastic Metal Product Co., Ltd. We main do all kinds of 3d design, 3d printing and plastic metal molds tooling and products. We have our own engineer and factory. One-stop supply:3d design - 3d printing - mold making - plastic injection.

5. What services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU;

Accepted Payment Currency:USD,EUR;

Accepted Payment Type: T/T,L/C,PayPal,Western Union,Escrow;

Language Spoken:English,Chinese,Spanish,French,Russian.

6. What are the characteristics of your service?

1. Your inquiry related to our products or prices will be replied within 24hours.

2. Welltrained and experienced staffs to answer all your enquiries in fluent English.

3. Offering the support to solve the problem in the application or selling period.

4. Competitive prices based on same quality.

5. Guarantee samples quality same as mass production quality.
