Ningbo (P&M) Plastic Hardware Products Co. has 15 years of mold making technology for customized Silicone baking tool kits Molding molds. We have ISO 9001 certificates. We provide professional custom mold service and we are professional plastic mold manufacturer. We have sufficient experience in product raw material selection and mold material selection. The Silicone baking tool kits Molding have relatively high requirements for the material softness. Usually We usually recommend pp, abs and some plastics. We are well aware of the properties of various materials and the advantages and disadvantages of mold design. We will recommend suitable materials and professional design advice for our clients.
We specialize in manufacturing high-performance silicone components for baking tool kits through advanced injection molding technologies. As a trusted supplier to kitchenware brands, bakery chains, and gourmet food companies, we deliver customized silicone parts that combine heat resistance, food safety, and ergonomic design. From mold design to semi-assembled modules, our services empower clients to create baking tools tailored to dough scrapers, spatulas, pastry brushes, and oven-safe molds – whether for home kitchens, commercial bakeries, or artisanal chocolate crafting.Whether you need individual silicone heads, reinforced handles, or pre-assembled multi-tool kits, our expertise ensures compliance with ISO9001.
Key Structures & Customization Options
1. Silicone Tool Heads
Design Flexibility:
Functional Shapes: Spatula blades (0.5–3mm thickness), dough scrapers, whisk covers, or basting brushes.
Surface Textures: Non-stick micro-patterns (Ra 5–30μm), embossed grips, or branded logos.
Heat Resistance: Withstand -40°C to 230°C for oven-to-freezer versatility.
Material Options:
Platinum-Cured LSR: FDA-compliant, odorless, and tear-resistant (≥500% elongation).
High-Hardness LSR (Shore A 50–70): Stiff edges for scraping without bending.
Thermally Conductive LSR: Embedded with ceramic fillers for even heat distribution.
2. Reinforced Handles & Connectors
Ergonomic Engineering:
Dual-Material Handles: Overmolded LSR on PP/PA cores for rigidity and heat insulation.
Anti-Slip Grips: Diamond knurling (Ra 20–80μm) or TPE overmolding (Shore A 40–60).
Quick-Release Joints: Magnetic or snap-fit connectors for interchangeable heads.
Material Choices:
Glass-Filled Nylon (PA66-GF30): Lightweight yet durable for commercial use.
Bamboo Fiber Composites: Eco-friendly option with natural aesthetics.
3. Multi-Tool Integration
Modular Systems:
Stackable Design: Nesting components (e.g., spatula + brush + scraper) with 2–5mm gaps.
Storage Hooks: Molded slots for wall-mounting or drawer organization.
Color Coding: Pantone-matched LSR for intuitive tool identification.
Functional Add-Ons:
Measurement Markings: Laser-etched刻度 (ml/oz) on spatula handles.
Integrated Thermometers: Pre-molded slots for temperature probes.
4. Specialty Features
Performance Enhancements:
Cutting Edges: Co-molded stainless steel inserts for dough scoring.
Non-Scratch Tips: Soft LSR coatings (Shore A 20) for delicate bakeware.
Material Selection Guide
1. Platinum-Cured LSR
Key Benefits:
Non-toxic, hypoallergenic, and resistant to oils/fats.
Autoclave-safe (134°C) for medical-grade hygiene.
Applications:
Baby food tools, high-end pastry spatulas.
2. Food-Grade TPE/TPU
Key Benefits:
Cost-effective alternative to LSR with similar flexibility.
LFGB compliant for EU market entry.
Applications:
Budget-friendly baking mats, silicone oven mitts.
3. Hybrid Materials
Options:
LSR-Coated Metal Cores: Stainless steel with silicone grips for heavy-duty use.
Conductive LSR: Carbon-filled for anti-static pastry brushes.
Bio-Based LSR: 30% plant-derived content for sustainable branding.
Advanced LSR Molding Capabilities
1. Precision Mold Design
Tooling Expertise:
Multi-cavity molds (up to 128 cavities) for high-volume efficiency (50,000+ units/month).
Heated molds (150–200°C) with vacuum systems to eliminate air traps.
Micro-precision EDM for 0.2mm thin edges on spatula blades.
Prototyping:
3D-printed food-safe prototypes in 48 hours for ergonomic testing.
Optimize blade flexibility (e.g., stiff for dough, soft for frosting).
Customize handle lengths (15–30cm) for ergonomic comfort.
Industries We Serve
Home & Retail: Non-stick baking mats, silicone muffin cups.
Commercial Kitchens: Heavy-duty scrapers, industrial dough blades.
Premium Brands: Gold-accented pastry brushes, designer cake molds.
Home kitchens, industrial bakeries, culinary schools.
We are plastic mold maker and can provide custom mold service, we can make injection molds, blow molds, rotational molds and die-casting molds.
For custom injection molds, we can provide professional custom injection molding services. Usually Silicone baking tool kits Molding are manufactured using injection molding technology. The mold materials for injection molds can be chosen from P20, 718, S136, H13 and so on. The mold material reflects the mold life and product material requirements.
For parts that require blow molding production, we can also provide professional custom blow molding services.
Product Name |
Silicone baking tool kits Molding
|
Pls provide |
2D, 3D, samples, or the size of the multi-angle pictures |
Mould Time |
20-35 Days |
Product time |
7-15 Days |
Mould precision |
+/-0.01mm |
Mould life |
50-100 million shots |
Producing Process |
Audit drawings - mold flow analysis - design validation - Custom Materials - mold processing - core processing - electrode machining - Runner system processing - parts processing and procurement - machining acceptance - cavity surface treatment process - complex mode Die - The entire mold surface coating - Mounting plate - mold sample - sample test - sending samples |
Mould cavity |
One cavity, multi-cavity or same different products be made together |
Mould material |
P20,2738,2344,718,S136,8407,NAK80,SKD61,H13 |
Runner system |
Hot runner and cold runner |
Base material |
P20,2738,2344,718,S136,8407,NAK80,SKD61,H13 |
Finish |
Pitting the word, mirror finish, matte surface, striae |
Standard |
HASCO, DME or dependent upon |
Main technology |
Milling, grinding, CNC, EDM, wire cutting, carving, EDM, lathes, surface Finish, etc. |
Software |
CAD,PRO-E,UG Design Time: 1-3 days (normal circumstances) |
Product material |
ABS,PP,PC,PA6,PA66,TPU,POM,PBT,PVC,HIPS,PMMA,TPE,PC/ABS,TPV,TPO,TPR,EVA,HDPE,LDPE,CPVC,PVDF,PPSU.PPS. |
Quality system |
ISO9001:2008 |
Establish time |
20days |
Equipment |
CNC,EDM,Cutting off Machine,plastic machinery,etc plastic suitcase mould zhe jiang |
Plastic Silicone baking tool kits Injection Mould making
1.We communicate product design according to samples/drawings and your requirements.
2.After the product design is confirmed, we carry out the mold design, we provide all kinds of injection molds, blow molds, silicone molds, die-casting molds services.
3.Material procurement, steel cutting and mold basic tools.
4.Mold assembly
5.Mold inspection, tracking and controlling mold processing.
6. We will inform you the date of mold trial and send you the sample inspection report and injection parameters together with the sample.
7.Your instruction and confirmation of shipment.
8.Prepare the mold before packing.
Plastic Silicone baking tool kits molding Specification
1. Professional manufacturer, design, production injection mould and stamping mould quality control
2. rich export experience plastic injection mould and stamping mould
3. Reasonable price of design mould
4. Cavities: single or as per your requirements cavity
5. Treatment: S45C Pretreat>25Hrc,And Nitriding
6. Mould Steel: Cavity ,Core and slide: P20 ,2738,2136 available Moldbase :LKM available
7. Standard:DEM ,HUSKY,available
8. Hot runner: according to your demand
9. Life time: >300 Thousand Times
10. Package: Plywood case, anti-rust paint
Mold design:
Information you need to provide us
1. If you have drawings, 2D drawings, 3D drawings (preferably in STEP format).
2. If there are no drawings, you need to provide specific length, width, height and weight information. (It’s best to send us samples)
3. Should the mold be sent to your country, or leave the mold in our factory and we will help you produce the product.
4. Mold material requirements, cavity number requirements (you can tell us about the size of your injection molding machine)
5. Product material requirements and product quantity. (You can tell us about the use of the product and we can give you suggestions)
Mold testing:
Once the mold is complete, I do a mold test. It usually takes about 3-5 days to complete. We need to assemble the mold, adjust the pressure data of the machine, and try production. We need to check whether there are problems during the normal production of the mold and make modifications.
Packaging according to your needs
1.By air ,it takes 3-7 days for delivery .The goods can be shipped by DHL ,Fedex ,UPS .
2.By sea ,the delivery time is based on your port .
To South East Asian Countries takes about 5-12 days
To Middle east countries takes about 18-25 days
To European countries takes about 20-28 days
To American countries takes about 28-35 days
To Australia takes about 10-15 days
To African countries takes about 30-35 days.
Video-1: (Factory Video)
Video-2: (Injection Molding)
Video-3: (Blow molding)
Video-4: (Blow molding)
Video-5: (Roll molding)
Customer satisfaction is our most important goal. We focus on communication and cooperation with our customers, always pay attention to their needs and provide quick response and quality customer service. Our injection production mold factory is committed to establishing long-term relationships and ensuring that our customers receive the best after-sales service during the purchase and use of our products, and we will definitely do our best to solve any problems for our customers.
1. Who are we?
We are based in Zhejiang, China, start from 2014,sell to North America(30.00%),Southern Europe(10.00%),Northern.
Europe(10.00%),Central America(10.00%),Western Europe(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%). There are total about 51-100 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
3. What can you buy from us?
Mould,Plastic Product, Metal Product,Dental Product,CNC machining.
4. Why should you buy from us not from other suppliers?
Ningbo P&M Plastic Metal Product Co., Ltd. We main do all kinds of 3d design, 3d printing and plastic metal molds tooling and products. We have our own engineer and factory. One-stop supply:3d design - 3d printing - mold making - plastic injection.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU;
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese,Spanish,French,Russian.
6. What are the characteristics of your service?
1. Your inquiry related to our products or prices will be replied within 24hours.
2. Welltrained and experienced staffs to answer all your enquiries in fluent English.
3. Offering the support to solve the problem in the application or selling period.
4. Competitive prices based on same quality.
5. Guarantee samples quality same as mass production quality.
