X-ray machine moulding

Ningbo (P&M) Plastic Metal Products Co., Ltd. has 17 years of mold manufacturing technology and can customize X-ray machine molds. We provide professional customized X-ray machine mold services, and we are a professional X-ray machine mold manufacturer. We have sufficient experience in selecting product raw materials and mold materials. In the process of customizing X-ray machine molds, our factory can provide one-stop service. We have design and production capabilities related to X-ray machines, such as: CAD design, mold manufacturing, injection molding, plastic product production, assembly and other technologies. In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized X-ray machine products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For X-ray machine products, we can make corresponding plastic parts, which is mainly done through injection molds.

X-ray machines must take into account the characteristics of radiation resistance, high precision, and biocompatibility. The core points of injection mold production are:

1. Material selection and modification

1). Radiation-resistant substrate

Use tungsten-nickel alloy reinforced mold steel (such as HOTVAR-WN), add 2.3% nano-tungsten particles to traditional S136 steel, so that the mold can withstand a cumulative radiation dose of 10^6 Gy (15 times that of ordinary molds)

The surface coating uses a gradient tantalum-gold composite film (thickness 0.05mm), which attenuates X-ray scattering energy by more than 30%

2). Biostability treatment

The housing mold of the implantable sensor needs to pass ISO 10993-2025 certified, titanium nitride (TiN) coating is used to prevent the precipitation of plastic degradation products

Add 0.01% lanthanide elements (such as cerium) to neutralize free radicals and extend the service life of parts in contact with iodine-containing contrast agents

2. Precision structural design

1). Radiation penetration compensation structure

Design 0.02-0.05mm micro-compensation surface in the filter grid molding area to offset the geometric distortion caused by the radiation hardening effect

Use asymmetric cooling water channels (front mold water channel spacing 1.5mm, rear mold 2.2mm) to balance the shrinkage differences in different wall thickness areas

2). Anti-static channel system

Integrated carbon nanotube conductive flow channel (resistivity ≤10^3 Ω·cm), to prevent CT rotating parts from adsorbing dust due to static electricity

Electromagnetic shielding cover is set at the gate (working frequency matches 2MHz-150kVp) to reduce interference from high-voltage generator

3. Intelligent manufacturing technology

1). Mold flow analysis: quantum computing-assisted simulation (predicting the deformation amount of radiation heat effect)

2). Electrode processing: graphene coated electrode (loss rate reduced by 55%)

3). Mold detection: terahertz wave three-dimensional scanning (accuracy ±0.002mm)

4). Surface treatment: Plasma electrolytic oxidation (PEO)

4. Response plan for special working conditions

1). Spring environmental adaptation

Workshop constant humidity system (45%±3%RH) linked to mold preheating temperature (set value + 3℃ to compensate for material moisture absorption and expansion)

Use phase change energy storage material (PCM) to wrap the mold frame to buffer the stress changes caused by the temperature difference between day and night (ΔT≤0.5℃)

2). Intelligent maintenance system

Embedded fiber grating sensor monitors mold radiation damage (accumulated dose＞800kGy automatic warning)

Predictive maintenance based on digital twin (generate 3D wear model every 5000 molds)

5. Verification and certification system

1). Functional test

Radiation penetration consistency test (density fluctuation <1.5% at 120kVp)

Low temperature brittleness test (-40℃ environment simulates transportation and storage)

10^6 times mold opening and closing life test (with barium compound-containing plastic material)

2). Medical compliance certification

Passed FDA 21 CFR 1020.30-2025 radiation protection standard

Obtain IEC 60601-2-54 3rd Edition Electrical Safety Certification

In terms of design:

High-precision structural design strategy

1. Dynamic optimization of parting surface and cavity

Radiation protection adaptation parting: Design a compensating parting surface (tolerance ±0.015mm) for the lead plate inlay area (thickness ≥2mm) to ensure that the radiation leakage is <0.5μSv/h (GBZ 130-2025 standard) after the shell is closed.

Heterogeneous material co-injection structure: At the junction of the protective layer (PC-ABS containing barium sulfate/tungsten powder) and the main structure (glass fiber reinforced PEEK), a two-color mold synchronous injection molding technology is used, and the interface bonding strength is ≥45MPa.

2. Demolding and ejection innovation

Magnetic field assisted demolding system: An electromagnetic device is embedded in the radiation protection area containing metal filling, and the demolding adsorption force is eliminated through a pulsed magnetic field (0.5T) to avoid surface scratches.

Bionic ejector layout: Optimize the ejector distribution density (spacing ≤15mm) with reference to the honeycomb structure, so that the shell flatness error is <0.1mm/m, meeting the image detector installation accuracy requirements
