In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized ice cream machine moulding products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For ice cream machine moulding products, we can make corresponding plastic parts, which is mainly done through injection molds.

Ice cream makers are classified as commercial or household refrigeration appliances. Their plastic housings operate continuously in environments characterized by low-temperature condensation, fluctuating thermal gradients, high humidity, and direct contact with food products; consequently, the materials must simultaneously satisfy requirements regarding aesthetic texture, structural integrity, thermal insulation fit, and dimensional stability. Key plastic components include the main body housing, top cover, dispensing port guard, drip tray, control panel, motor mount, and inner liner trim ring. The injection molding process must prioritize five core control parameters: low-temperature resistance and anti-condensation properties, dimensional stability (resistance to warping), food-grade safety compliance, high-gloss surface finish, and resistance to deformation caused by condensation. Compared to standard appliance housings, the overall manufacturing process places a greater emphasis on adaptability to temperature fluctuations and environmental reliability. The specific molding considerations are outlined below.

Material selection centers on four core criteria: resistance to thermal variation, resistance to condensation, food-grade safety, and high rigidity. For large exterior components—such as the main body housing and top cover—high-gloss ABS or heat-resistant modified PP are commonly employed. ABS offers superior surface gloss, ease of color matching, and stable shrinkage rates, making it ideal for the exposed exterior housings of high-end models; conversely, PP offers excellent toughness, low-temperature resistance, and moderate cost-effectiveness, rendering it suitable for structural components such as bases and protective covers. Finer components—such as control panels and decorative trim rings—typically utilize PC/ABS alloys, which offer enhanced rigidity and resistance to stress cracking, thereby preventing issues such as surface whitening or cracking caused by temperature differentials. Components that may come into direct contact with ice cream ingredients—such as the drip tray and the area surrounding the dispensing port—must be fabricated using food-grade PP or food-grade ABS to ensure compliance with food-contact safety standards, guaranteeing the absence of odors or toxic leachates. Given that ice cream makers experience significant internal-external temperature differentials during operation—leading to a propensity for condensation on the exterior housing—the selected materials must possess sufficient resistance to hydrolysis and stress cracking to prevent brittle fracture resulting from prolonged exposure to corrosive condensation. Regarding raw material pretreatment: ABS and PC/ABS exhibit high hygroscopicity and therefore require hot-air drying at 80–90°C for 3–4 hours to reduce moisture content below 0.03%; this prevents molding defects such as silver streaks, air bubbles, or a matte surface finish. PP, conversely, exhibits low hygroscopicity and typically does not require intensive drying; however, in humid environments, it should be preheated at 70°C for one hour to prevent surface moisture marks from compromising the aesthetic finish or assembly precision. For coloring, weather-resistant and anti-yellowing masterbatches are utilized at an additive ratio of 2%–4% to ensure that the product remains fade-free and color-stable over the long term.

The primary focus of the mold design is to address issues related to warping in large flat surfaces, deformation caused by temperature differentials, assembly precision, and demolding. Ice cream machine housings typically feature large dimensions, shallow cavities, expansive flat surfaces, and structures incorporating numerous assembly snaps and mounting holes. Consequently, the mold parting line must be positioned along the maximum contour—specifically avoiding the aesthetic exterior surfaces—and the mold shut-off clearance must be controlled to within 0.02 mm to minimize flash that could compromise assembly tightness and sealing integrity. The mold cavities and cores are fabricated using 718 or S136 mold steel, with surfaces polished to a roughness of Ra 0.02–0.05 μm to ensure a uniform surface gloss on the housing, eliminate weld lines, and facilitate easy cleaning. For housings with large flat surfaces, reinforcing ribs must be strategically positioned; the rib thickness should be 50%–60% of the nominal wall thickness to prevent deformation caused by temperature differentials and the component's own weight. Furthermore, assembly features and snap-fit locations require the incorporation of appropriate draft angles to prevent drag marks or "whitening" (stress marks) during demolding. Regarding dimensional precision, critical attention is paid to the interface dimensions with the refrigeration module, glass viewing window, and dispensing mechanism. Precise compensation is applied based on the material's shrinkage rate—specifically 0.5%–0.7% for ABS and 1.2%–1.8% for PP—to ensure uniform assembly gaps, prevent cold leakage, and eliminate looseness or rattling.

For the gating system, a hot runner system is the preferred choice; for large-format housings, a multi-point gating configuration is employed to ensure rapid and uniform melt filling, thereby minimizing weld lines associated with long flow paths and reducing internal residual stress. The gates are designed as either submarine gates or side gates, positioned in inconspicuous locations to avoid compromising the product's aesthetic appearance. The cooling system is the critical factor in controlling deformation; cooling channels must be distributed uniformly across the housing's large flat surfaces, with channel density increased in areas of greater wall thickness. Mold temperature fluctuations are strictly controlled to within ±3°C to ensure uniform cooling and minimize warping. Finally, the venting design requires particular emphasis; vent channels with a depth of 0.02–0.03 mm are strategically placed at the ends of cavities, at corners, and at the bases of reinforcing ribs to prevent air entrapment—which can lead to short shots, burn marks, or flow lines—and to preclude the encapsulation of air within the melt, which could result in internal porosity within the housing structure. For undercut features—such as side latches and mounting slots—slider or angled lifter core-pulling mechanisms are employed to ensure smooth demolding and dimensional stability.

Injection molding process parameters are controlled with the primary objectives of minimizing internal stress, preventing warping, maintaining dimensional stability, and achieving a high-gloss finish. Equipment selection focuses on injection molding machines with a clamping force of 200–600 tons, utilizing an injection volume equivalent to 1.2–1.5 times the product weight to ensure thorough plasticization and stable injection. Temperature settings are configured in a gradient: for ABS material, the barrel temperatures are set to 240–260°C in the front section, 230–250°C in the middle section, and 210–230°C in the rear section; the mold temperature is maintained at 50–70°C to enhance surface gloss and reduce internal stress. For PP material, the barrel temperature is set to 190–220°C and the mold temperature to 40–60°C to balance crystallization shrinkage and minimize deformation caused by temperature differentials. Injection speed is controlled in stages: an initial low-speed injection prevents jetting and the formation of "gate blush" (halo marks); a medium-speed phase fills the main body of the part; and a final low-speed phase maintains pressure stability to prevent air entrapment and flash.

Injection pressure is set between 80–130 MPa, depending on wall thickness and dimensional requirements, with pressure appropriately increased for shells featuring large flat surfaces. Holding pressure is set to 60%–75% of the injection pressure, with a holding time of 12–25 seconds, specifically to compensate for shrinkage in assembly features and thick-walled sections, thereby eliminating sink marks and depressions. Back pressure is maintained at 3–6 MPa to improve melt homogeneity and prevent color variations or mixing defects. Cooling time is controlled between 25–45 seconds, based on wall thickness, to ensure the product is fully solidified and remains free of deformation or mold adhesion during ejection. Ejection is executed using a combined ejector plate and pin system to ensure uniform force distribution, thereby preventing "ejector whitening" (stress marks) or cracking—particularly avoiding visible ejection marks on large flat surfaces.

Post-processing and quality inspection procedures are tailored to meet the specific environmental requirements of the ice cream machine application. After molding, gates, flash, and burrs are meticulously removed. Cosmetic parts undergo inspection for gloss, color consistency, scratches, and weld lines; structural parts are inspected for assembly hole spacing, flatness, and latch strength. Dimensional tolerances are controlled within ±0.05–0.1mm to ensure precise fitment with the refrigeration system, machine head, and drip tray. Key reliability tests include: low-temperature environment testing—withstanding exposure to temperatures between -10°C and 0°C for 2–4 hours without cracking or whitening; condensation testing—simulating operational temperature differentials to verify the absence of deformation or dripping; and safety and odor testing for food-contact components—ensuring no off-odors or toxic leaching.

Common Defects and Preventive Measures: Warping on large flat surfaces of the housing is often caused by uneven cooling or improper holding pressure; this requires optimizing cooling channel layouts, extending cooling times, and adjusting mold temperatures. Sink marks and depressions result from overly thick ribs or insufficient holding pressure; structural designs should be optimized, and holding pressure increased. Silver streaks and surface haziness are caused by moisture in the raw materials; strict drying protocols must be enforced. Prominent weld lines can be mitigated by increasing mold temperatures and injection speeds, as well as enhancing mold venting. Flash and burrs are typically caused by insufficient clamping force or mold wear; clamping force must be increased, and the mold's parting line repaired.

Overall, the core principles for the injection molding of plastic housings for ice cream machines involve controlling deformation caused by temperature differentials, ensuring dimensional stability, achieving food-grade safety standards, and enhancing surface aesthetics. Through meticulous control across the entire process—encompassing materials, mold design, processing parameters, and quality inspection—the housing can be ensured to remain free from deformation, cracking, or yellowing over the long term, even when exposed to low temperatures, high humidity, and fluctuating thermal environments, thereby satisfying the durability and aesthetic requirements for both commercial and domestic ice cream machines.

We are a ice cream machine moulding manufacturer, providing high-quality ice cream machine moulding manufacturing. As long as you want to customize/develop ice cream machine moulding products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.
