Mechanical arm moulding

The production requirements of medical robotic arms are very high, and all details need to be paid attention to

1. Design challenges and innovative breakthroughs

Adaptation of complex geometric structures

Bionic joint module: For the multi-degree-of-freedom joints of the robotic arm (such as the 6-axis structure of the wrist), multi-slider linkage + rotary core pulling technology is adopted, the mold has up to 32 movable parts, and the parting surface accuracy must reach ±0.005mm.

Lightweight topology optimization: Based on AI generative design (Autodesk Fusion 360 2025), the support structure is reduced by 40% while ensuring the joint strength (load>500N).

Functional integration requirements

Embedded sensor slot: The mold reserves the fiber channel and pressure sensor installation position (accuracy ±0.1kPa), and the biological signal acquisition module is molded synchronously during injection molding;

Antibacterial coating co-injection: Using two-color injection molding technology, PEEK-Matrix material containing nanosilver (antibacterial rate ≥99.9%) is injected into the skin contact area (such as the gripping end).

2. Material and process system

Special medical plastics: PEEK-Carbon (carbon fiber reinforced, elastic modulus 24GPa), resistant to gamma ray sterilization (100kGy dose)

Microporous breathable structure: supercritical nitrogen foaming (pore size 10-50μm, density reduced by 30%), air permeability increased to 5L/(m²·s)

Surface functional treatment: laser microtexturing (pit depth 0.1-0.3μm, spacing 50μm), friction coefficient reduced to 0.08, reducing tissue damage

3. Key technologies for precision manufacturing

Five-axis linkage machining:

Using DMG MORI Ultrasonic 20 (ultrasonic vibration assisted machining), the cutting speed is increased to 120m/min, achieving 0.001mm surface finish (Ra≤0.02μm).

For 0.2mm thin-walled structures (such as finger joint shells), nano-scale micro-milling (tool diameter 0.03mm, speed 80,000rpm) is used.

Intelligent temperature control system:

The mold is embedded with 3D conformal cooling water channels (printed in titanium alloy, 0.5mm in diameter), with a mold temperature uniformity of ±0.3℃, eliminating shrinkage marks caused by temperature differences (shrinkage rate <0.05%).

Real-time monitoring of melt temperature (infrared thermal imager + thermocouple dual feedback) ensures that the crystallinity of PEEK materials is stable at 35-40%.

4. Cost and efficiency optimization

Modular design

Develop replaceable insert systems (such as wrist/finger/elbow modules), with a switching time of ≤2 hours and a mold reuse rate of 70%;

Use blockchain technology to trace raw material batches (full-link traceability from particles to finished products).

AI-assisted production

Training defect prediction models (based on NVIDIA Omniverse) reduces the number of mold trials from 8 to 3, and shortens the development cycle to 55 days;

Dynamically adjust injection molding parameters (holding pressure ±0.5MPa, cooling time ±0.5s), and the yield rate is increased to 99.2%.

4D printing mold: shape memory alloy mold can adapt to different types of robot arm production (switching response time <30 minutes);

Quantum sensing monitoring: implant quantum dot sensors to monitor mold stress distribution in real time (accuracy up to 0.1MPa level）

Functional verification

Motion accuracy test: simulate 100,000 grasping actions (load 200N) in ISO Class 5 clean room, joint gap change ≤0.005mm;

Biocompatibility: passed ISO 10993-5 cytotoxicity test (cell survival rate ≥90%), heavy metal precipitation (such as nickel, chromium) <0.001μg/cm²

Regulatory certification

Complies with FDA 21 CFR 880.2925 (surgical robot parts) and EU MDR 2025 Class IIb standards;

Mold digital twins must pass ISO/ASTM 52920 certification (additive manufacturing data integrity)
