Plastic pad mold

We specialize in custom plastic pad mold development, plastic pad component production, and optional assembly services—not finished product trading. Our molds are engineered to match your plastic pads’ unique needs (e.g., ultra-thin thickness, insulation performance, sealing edges) , with tailored structures, material compatibility, and optimized injection molding to deliver high-performance plastic pad parts for electronics, furniture, and industrial equipment.

1. Custom Mold Structures: Tailored to Plastic Pad Requirements

Plastic pads (e.g., electronics insulation pads, furniture buffer pads, equipment sealing pads) demand extreme flatness, precise thickness control, and functional adaptability—our mold structures are customized to address these key demands:

Cavity & Core: Machined via high-precision CNC grinding (tolerance as tight as ±0.01mm for thickness, ±0.02mm for size) to ensure uniform pad thickness (0.1–3mm, based on use) and clean edges. For pads with holes (e.g., for fixation or wire passage), the mold’s core pins are calibrated to ±0.005mm to avoid hole misalignment. Surface polishing (Ra ≤0.2μm) ensures the pad has no burrs—critical for insulation or sealing functions.

Gating System: Designed for thin pad filling without damaging surface integrity. Micro edge gates (width 0.8–1.2mm, positioned at non-functional edges) or tab gates (small extended tabs for easy trimming) are used—they leave minimal residues and avoid affecting the pad’s flatness. For ultra-thin pads (≤0.3mm), hot runner systems with micro nozzles ensure stable plastic flow, reducing material waste by 12–18%.

Cooling System: Optimized for thin, flat pad designs. Parallel cooling plates (spaced 5–8mm apart) cover the entire mold cavity, ensuring even heat dissipation—preventing warping (a major issue for thin pads) and reducing cooling time by 25–35%. For pads with localized thickened areas (e.g., sealing edges), additional cooling pins are added to maintain uniform temperature.

Ejection System: Uses ultra-thin ejector pins (diameter 0.8–1.5mm, arranged in a matrix) or stripper plates to avoid pad deformation. Ejector force is precisely controlled to ensure the pad is released flat—no bending or creasing that would compromise its insulation or sealing performance.

2. Suitable Plastic Materials: Matched to Plastic Pad Applications

Plastic pads serve diverse functional roles (insulation, buffer, sealing, wear resistance)—we select materials based on performance needs, environmental adaptability, and use scenarios:

PET (Polyethylene Terephthalate): Ideal for electronics insulation pads (e.g., PCB board isolation pads, battery buffer pads). Offers excellent electrical insulation (dielectric strength ≥15kV/mm), high temperature resistance (up to 120°C), and good mechanical strength—prevents short circuits and withstands electronic device operating temperatures.

PE (Polyethylene): Used for lightweight buffer pads (e.g., furniture leg pads, packaging protection pads). Provides good impact resistance, low friction coefficient (avoids surface scratches), and chemical resistance (to water, oils)—suitable for low-load, non-high-temperature indoor scenarios.

Silicone-Modified PP: Perfect for sealing pads (e.g., equipment junction pads, kitchen appliance waterproof pads). Combines PP’s rigidity with silicone’s elasticity—offers good sealing performance (prevents water/dust ingress) and temperature resistance (up to 100°C), compatible with humid environments.

PTFE (Polytetrafluoroethylene): Great for high-performance industrial pads (e.g., machinery sliding pads, high-temperature equipment insulation pads). Features extreme temperature resistance (-200°C to 260°C), chemical inertness (resistant to most acids/alkalis), and low friction coefficient—suitable for harsh industrial conditions.

TPU (Thermoplastic Polyurethane): Suitable for flexible buffer pads (e.g., electronic device anti-drop pads, sports equipment cushion pads). Offers high elasticity (Shore A 60–80) for shock absorption, wear resistance, and transparency—ideal for applications requiring both protection and aesthetics.

3. Injection Molding Process: Optimized for Plastic Pad Quality

Our injection molding process is fine-tuned to solve common thin pad issues (filling difficulty, warping, surface defects) with these core advantages:

Thickness Consistency: Low-pressure (50–80MPa) and precise temperature control (180–240°C, material-dependent) ensure plastic fills the cavity evenly—each pad’s thickness variation is kept within ±0.01mm, meeting strict insulation or sealing requirements.

Surface Integrity: Mold cavity polishing (Ra ≤0.2μm) and controlled injection speed (30–50mm/s) eliminate surface defects like sink marks or bubbles. Post-molding inspection via optical scanners checks for flatness and burrs, with a defect rate below 0.2%.

Efficient Mass Production: Multi-cavity molds (32–64 cavities, based on pad size) maximize output. For standard 20×20mm pads (0.5mm thick), daily production reaches 100,000–150,000 components. Automated trimming and sorting systems reduce labor costs and ensure consistent quality.

Cost Optimization: Hot runner systems minimize material waste; for high-volume orders (200,000+ pads), per-unit cost can be reduced by 10–15%. Two-shot molding is optional for pads needing dual properties (e.g., rigid core + flexible edge), integrating functions in one step.

4. Our Services: Beyond Molds—Plastic Pads & Assembly

We provide end-to-end solutions for plastic pad production, not just molds:

Plastic Pad Manufacturing: Produce custom pads in various sizes (5×5mm to 200×200mm), thicknesses (0.1–3mm), and designs (solid, perforated, with adhesive layers). Supports custom colors (RAL/Pantone codes) or surface treatments (anti-static coating, flame-retardant finishing).

Value-Added Assembly: Optional assembly services for pad sub-assemblies—such as attaching double-sided adhesive tapes (for easy installation), laminating with metal foils (for enhanced conductivity), or cutting pads into complex shapes (for equipment fitting). Delivers ready-to-integrate sub-assemblies, saving your production time.

Custom Design Support: Offer 3D mold design and rapid prototyping (via SLA 3D printing). We can produce 30–50 prototype pads in 2–3 days for you to test insulation performance, buffer effect, or sealing tightness—optimizing the mold design before mass production.

We are plastic mold maker and can provide custom mold service, we can make injection molds, blow molds, rotational molds and die-casting molds.

For custom injection molds, we can provide professional custom injection molding services. Usually Plastic injection mold manufacturing Molding are manufactured using injection molding technology. The mold materials for injection molds can be chosen from P20, 718, S136, H13 and so on. The mold material reflects the mold life and product material requirements.

For parts that require blow molding production, we can also provide professional custom blow molding services.

Plastic injection mold manufacturing Injection Mould making

1.We communicate product design according to samples/drawings and your requirements.

2.After the product design is confirmed, we carry out the mold design, we provide all kinds of injection molds, blow molds, silicone molds, die-casting molds services.

3.Material procurement, steel cutting and mold basic tools.

4.Mold assembly

5.Mold inspection, tracking and controlling mold processing.

6. We will inform you the date of mold trial and send you the sample inspection report and injection parameters together with the sample.

7.Your instruction and confirmation of shipment.

8.Prepare the mold before packing.

Plastic injection mold manufacturing molding Specification

1. Professional manufacturer, design, production injection mould and stamping mould quality control

2. rich export experience plastic injection mould and stamping mould

3. Reasonable price of design mould

4. Cavities: single or as per your requirements cavity

5. Treatment: S45C Pretreat>25Hrc,And Nitriding

6. Mould Steel: Cavity ,Core and slide: P20 ,2738,2136 available Moldbase :LKM available

7. Standard:DEM ,HUSKY,available

8. Hot runner: according to your demand

9. Life time: >300 Thousand Times

10. Package: Plywood case, anti-rust paint

Mold design：

Information you need to provide us

1. If you have drawings, 2D drawings, 3D drawings (preferably in STEP format).

2. If there are no drawings, you need to provide specific length, width, height and weight information. (It’s best to send us samples)

3. Should the mold be sent to your country, or leave the mold in our factory and we will help you produce the product.

4. Mold material requirements, cavity number requirements (you can tell us about the size of your injection molding machine)

5. Product material requirements and product quantity. (You can tell us about the use of the product and we can give you suggestions)

Transaction process:

Mold testing：

Once the mold is complete, I do a mold test. It usually takes about 3-5 days to complete. We need to assemble the mold, adjust the pressure data of the machine, and try production. We need to check whether there are problems during the normal production of the mold and make modifications.

Product packaging

Packaging according to your needs

1.By air ,it takes 3-7 days for delivery .The goods can be shipped by DHL ,Fedex ,UPS .

2.By sea ,the delivery time is based on your port .

To South East Asian Countries takes about 5-12 days

To Middle east countries takes about 18-25 days

To European countries takes about 20-28 days

To American countries takes about 28-35 days

To Australia takes about 10-15 days

To African countries takes about 30-35 days.

Factory

Video-1: (Factory Video)

Video-2: (Injection Molding)

Video-3: (Blow molding)

Video-4: (Blow molding)

Video-5: (Roll molding)

Customer satisfaction is our most important goal. We focus on communication and cooperation with our customers, always pay attention to their needs and provide quick response and quality customer service. Our injection production mold factory is committed to establishing long-term relationships and ensuring that our customers receive the best after-sales service during the purchase and use of our products, and we will definitely do our best to solve any problems for our customers.
