TPE plastic mold

We specialize in custom TPE plastic mold development, TPE (Thermoplastic Elastomer) component production, and optional assembly services—not finished product trading. Our molds are engineered to maximize TPE’s unique advantages (soft tactile feel, high elasticity, recyclability) while addressing its molding challenges (e.g., mold adhesion, low rigidity), delivering high-quality TPE parts for consumer electronics, medical devices, baby products, and household goods.

1. Custom Mold Structures: Tailored to TPE’s Molding Characteristics

TPE’s distinct properties (low hardness, high flexibility) require molds that enhance its soft-touch performance and ensure easy demolding. Our custom mold structures include:

Cavity & Core: Machined via high-precision CNC machining (tolerance as tight as ±0.02mm) to suit TPE’s needs:

Textured or smooth surfaces (Ra ≤0.8μm) to replicate TPE’s soft tactile feel—critical for parts like phone cases, baby bottle handles, or remote control grips, where touch comfort directly impacts user experience.

Uniform wall thickness (0.5–3mm) with rounded edges—TPE’s low rigidity makes it prone to deformation in uneven sections; consistent thickness avoids weak points (e.g., tearing at thin edges of grip parts) and ensures uniform elasticity.

Anti-adhesion coatings (e.g., PTFE-based) on cavity surfaces—TPE’s high viscosity and stickiness increase demolding difficulty; coatings reduce friction, enabling scratch-free part removal without damaging TPE’s soft structure.

Gating System: Designed for TPE’s moderate melt viscosity (MFR 1–15 g/10min):

Small-diameter pin gates (0.5–1mm) for small soft parts (e.g., earbud tips, medical seal rings)—enables precise flow control, reducing gate marks that affect tactile feel (critical for parts in direct contact with skin).

Hot runner systems with temperature control (160–200°C) for multi-cavity or two-shot molding (e.g., TPE-overmolded plastic grips)—maintains TPE’s melt stability, cuts material waste by 18–25%, and ensures strong bonding with rigid plastics (e.g., ABS, PP) in overmolding applications.

Cooling System: Calibrated to control TPE’s fast cooling and elasticity retention:

Evenly spaced cooling channels (8–12mm apart) with moderate temperature (40–60°C)—TPE’s fast crystallization requires controlled cooling to preserve elasticity; rapid cooling can make TPE brittle, while slow cooling reduces production efficiency.

Cooling inserts for thickened TPE areas (e.g., grip bulges)—reduces cooling time by 25–35%, avoiding sink marks that ruin tactile comfort and structural integrity.

Ejection System: Suited to TPE’s flexibility and low rigidity:

Wide, flat ejector pins (arranged at non-visible, high-strength areas)—distributes ejection force evenly to avoid stretching or tearing TPE’s soft structure (e.g., thin-walled seal rings).

Stripper plates for large TPE parts (e.g., yoga mat edges, appliance door gaskets)—gently releases parts without deforming their shape, ensuring consistent elasticity and fit.

2. TPE Material Variants & Their Applications

TPE is available in modified grades to match specific tactile and performance needs—we select the right variant based on your component’s function and contact scenario:

TPS (Thermoplastic Styrenic Elastomer): Ideal for consumer soft-touch parts (e.g., phone cases, remote control grips, toy handles). Offers Shore A hardness 30–90 (adjustable for different softness), good elasticity (≥300% elongation), and easy coloring—suitable for indoor, low-stress applications where tactile feel is priority.

TPR (Thermoplastic Rubber): Used for skin-contact parts (e.g., baby bottle nipples, medical gloves, earbud tips). Features hypoallergenic properties (meets FDA standards), excellent skin compatibility, and good oil resistance—safe for prolonged contact with human skin, ideal for baby products and medical devices.

TPU (Thermoplastic Polyurethane): Perfect for durable, high-tensile TPE parts (e.g., sports equipment grips, phone screen protectors, industrial seal rings). Boasts high tensile strength (up to 60 MPa), abrasion resistance, and weather resistance—withstands outdoor exposure and frequent use, suitable for sports and industrial applications.

TPO (Thermoplastic Olefin): Great for low-cost, outdoor TPE parts (e.g., garden tool grips, automotive door seals). Offers good weather resistance (no cracking under UV exposure), low temperature flexibility (down to -40°C), and chemical resistance—ideal for outdoor or harsh-environment applications.

TPV (Thermoplastic Vulcanizate): Suitable for high-temperature or high-stress parts (e.g., automotive under-hood seals, industrial hoses). Combines TPE’s processability with rubber’s heat resistance (up to 150°C) and compression set resistance—maintains elasticity under high temperatures, suitable for automotive and industrial use.

3. TPE Injection Molding Process: Optimized for Performance

Our injection process is fine-tuned to maximize TPE’s softness, elasticity, and production efficiency, with key advantages:

Tactile & Elastic Consistency:

Melt temperature control (160–220°C, grade-dependent)—TPE degrades above 240°C; precise heating ensures optimal flow without material breakdown, preserving softness and elasticity (critical for touch-sensitive parts).

Injection pressure (50–80 MPa) with slow injection speeds—balances TPE’s viscosity to avoid overfilling (which causes flash) or underfilling (which ruins shape), ensuring uniform softness across all parts.

Post-molding elasticity testing (elongation and compression set)—each batch is tested to confirm TPE retains ≥80% elasticity after 10,000 cycles, ensuring long-term performance.

Overmolding Compatibility:

Two-shot molding expertise for TPE-overmolded parts—optimizes temperature and pressure to ensure strong bonding between TPE and rigid plastics (e.g., ABS, PP), eliminating delamination (a common issue in low-quality overmolding).

Customizable bonding strength—adjusts process parameters to meet different application needs (e.g., permanent bonding for phone grips, removable bonding for replaceable seal rings).

Efficiency & Cost-Effectiveness:

Fast cycle times (15–30 seconds per part)—TPE’s fast cooling enables efficient production; for small parts like earbud tips, multi-cavity molds (32–64 cavities) support daily output up to 80,000 components.

Recyclable material utilization—TPE scrap can be reused (up to 20% of raw material), reducing waste and lowering per-unit costs for large orders.

4. Our Services: Beyond Molds—TPE Components & Assembly

We provide end-to-end solutions for TPE production, tailored to soft-touch and elastic needs:

TPE Component Manufacturing: Produce custom TPE parts in sizes (3×3mm to 500×300mm), shapes (grips, seals, tips), and Shore A hardness (30–90). Supports color matching (RAL/Pantone codes) and surface treatments (anti-slip texture, matte finish) to enhance tactile feel.

Value-Added Assembly: Optional assembly services for TPE sub-assemblies—e.g., overmolding TPE onto plastic frames (for grips), bonding TPE seal rings to metal parts (for industrial valves), or assembling TPE-based kits (e.g., baby bottle nipple sets). Delivers ready-to-install sub-assemblies, saving your production time.

Custom Design Support: Offer 3D mold design and TPE prototyping (via injection molding or 3D printing). We produce 20–50 prototype parts in 2–3 days to test TPE’s tactile feel, elasticity, and bonding strength—optimizing the mold design before mass production.

We are plastic mold maker and can provide custom mold service, we can make injection molds, blow molds, rotational molds and die-casting molds.

For custom injection molds, we can provide professional custom injection molding services. Usually Plastic injection mold manufacturing Molding are manufactured using injection molding technology. The mold materials for injection molds can be chosen from P20, 718, S136, H13 and so on. The mold material reflects the mold life and product material requirements.

For parts that require blow molding production, we can also provide professional custom blow molding services.

Plastic injection mold manufacturing Injection Mould making

1.We communicate product design according to samples/drawings and your requirements.

2.After the product design is confirmed, we carry out the mold design, we provide all kinds of injection molds, blow molds, silicone molds, die-casting molds services.

3.Material procurement, steel cutting and mold basic tools.

4.Mold assembly

5.Mold inspection, tracking and controlling mold processing.

6. We will inform you the date of mold trial and send you the sample inspection report and injection parameters together with the sample.

7.Your instruction and confirmation of shipment.

8.Prepare the mold before packing.

Plastic injection mold manufacturing molding Specification

1. Professional manufacturer, design, production injection mould and stamping mould quality control

2. rich export experience plastic injection mould and stamping mould

3. Reasonable price of design mould

4. Cavities: single or as per your requirements cavity

5. Treatment: S45C Pretreat>25Hrc,And Nitriding

6. Mould Steel: Cavity ,Core and slide: P20 ,2738,2136 available Moldbase :LKM available

7. Standard:DEM ,HUSKY,available

8. Hot runner: according to your demand

9. Life time: >300 Thousand Times

10. Package: Plywood case, anti-rust paint

Mold design：

Information you need to provide us

1. If you have drawings, 2D drawings, 3D drawings (preferably in STEP format).

2. If there are no drawings, you need to provide specific length, width, height and weight information. (It’s best to send us samples)

3. Should the mold be sent to your country, or leave the mold in our factory and we will help you produce the product.

4. Mold material requirements, cavity number requirements (you can tell us about the size of your injection molding machine)

5. Product material requirements and product quantity. (You can tell us about the use of the product and we can give you suggestions)

Transaction process:

Mold testing：

Once the mold is complete, I do a mold test. It usually takes about 3-5 days to complete. We need to assemble the mold, adjust the pressure data of the machine, and try production. We need to check whether there are problems during the normal production of the mold and make modifications.

Product packaging

Packaging according to your needs

1.By air ,it takes 3-7 days for delivery .The goods can be shipped by DHL ,Fedex ,UPS .

2.By sea ,the delivery time is based on your port .

To South East Asian Countries takes about 5-12 days

To Middle east countries takes about 18-25 days

To European countries takes about 20-28 days

To American countries takes about 28-35 days

To Australia takes about 10-15 days

To African countries takes about 30-35 days.

Factory

Video-1: (Factory Video)

Video-2: (Injection Molding)

Video-3: (Blow molding)

Video-4: (Blow molding)

Video-5: (Roll molding)

Customer satisfaction is our most important goal. We focus on communication and cooperation with our customers, always pay attention to their needs and provide quick response and quality customer service. Our injection production mold factory is committed to establishing long-term relationships and ensuring that our customers receive the best after-sales service during the purchase and use of our products, and we will definitely do our best to solve any problems for our customers.

FAQ

1. Who are we?

We are based in Zhejiang, China, start from 2014,sell to North America(30.00%),Southern Europe(10.00%),Northern.

Europe(10.00%),Central America(10.00%),Western Europe(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%). There are total about 51-100 people in our office.

2. How can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment.

3. What can you buy from us?

Mould,Plastic Product, Metal Product,Dental Product,CNC machining.

4. Why should you buy from us not from other suppliers?

Ningbo P&M Plastic Metal Product Co., Ltd. We main do all kinds of 3d design, 3d printing and plastic metal molds tooling and products. We have our own engineer and factory. One-stop supply:3d design - 3d printing - mold making - plastic injection.

5. What services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU;

Accepted Payment Currency:USD,EUR;

Accepted Payment Type: T/T,L/C,PayPal,Western Union,Escrow;

Language Spoken:English,Chinese,Spanish,French,Russian.

6. What are the characteristics of your service?

1. Your inquiry related to our products or prices will be replied within 24hours.

2. Welltrained and experienced staffs to answer all your enquiries in fluent English.

3. Offering the support to solve the problem in the application or selling period.

4. Competitive prices based on same quality.

5. Guarantee samples quality same as mass production quality.
