ABS plastic car parts custom moulding

In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized customized abs plastic injection parts moulding products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For customized abs plastic injection parts moulding products, we can make corresponding plastic parts, which is mainly done through injection molds.

Phase 1: Requirements Analysis and Design - The Cornerstone of Success

This is the starting point of the project, aiming to "do it right the first time."

In-depth Requirements Communication:

Functional Requirements: Part's operating environment, load, temperature resistance, chemical resistance, flame retardancy rating (e.g., UL94 V-0).

Appearance Requirements: Surface treatment (high gloss, matte, textured, spray painting, electroplating), color (provide Pantone color code).

Precision and Regulations: Dimensional tolerances (comply with GD&T standards), assembly requirements, industry certifications (e.g., FDA, RoHS).

Budget and Timeline: Target cost, project timeline, expected output.

Product Design Optimization and DFM (Design for Manufacturability Analysis):

Core Value Element: Close collaboration between the mold supplier and your design team.

Analysis Content:

Wall Thickness Uniformity: Recommended 2.5-3.0mm to avoid shrinkage and warping.

Draft Angle: Ensure smooth demolding, typically ≥1°.

Reinforcing Ribs and Screw Studs: Rationally designed (rib thickness ≤ 60% of main body wall thickness) to prevent back shrinkage.

Rounded Corner Transitions: Avoid stress concentration and improve plastic flow.

Parting Line Determination: Select the location with minimal impact on aesthetics and function.

Gate Location and Type: Evaluate the optimal gate point, balance filling, and reduce weld lines.

Output: Professional DFM report providing detailed optimization suggestions and confirmation with you.

Material Selection:

ABS Basic Characteristics: High strength, good toughness, easy to process, easy to dye, and easy to surface treat.

Grade Selection:

General Purpose Grade: Most commonly used.

High Impact Grade: Used for parts requiring higher toughness.

Heat Resistant Grade: Used for parts operating in high-temperature environments.

Electroplated Grade: Specifically for applications requiring electroplating.

Second Stage: Mold Design and Manufacturing - The Birth of Precision Tools

The mold is the "mother" of the product; its quality directly determines the quality of the parts.

Mold Design:

Mold Flow Analysis: A standard feature of modern precision injection molding. Computer simulations of plastic filling, cooling, shrinkage, and warpage predict and resolve issues such as air pockets, weld lines, and shrinkage, optimizing the gating and cooling systems.

Structural Design: Design of the mold base, cavities/cores, slides/ejectors (for undercuts), cooling channels, and venting systems.

Precision Machining and Assembly:

Machining Processes: Machining of mold cores and inserts using CNC (Computer Numerical Control), EDM (Electrical Discharge Machining), and wire cutting processes.

Surface Treatment: Specific treatments for the cavities, such as mirror polishing (for high-gloss surfaces) and VDI texturing (e.g., leather texture).

Mold Assembly (Fitting): Precision assembly and adjustment of all parts by a senior fitter to ensure smooth and error-free movement of all components.

Third Stage: Mold Trial and Process Optimization - Verification and Fine-tuning

This is the crucial bridge connecting the mold to mass production.

Initial Trial Molding (T0): Install the mold on the injection molding machine, perform preliminary adjustments using production materials, and produce the first batch of samples.

ABS-Specific Process Adjustment Points:

Material Drying: ABS must be dried at 80-85℃ for 2-4 hours to prevent silver streaks on the product surface.

Mold Temperature: Use a relatively high mold temperature of 60-80℃. High mold temperature is key to obtaining a high-gloss surface, reducing weld lines, and lowering internal stress.

Injection Speed: Medium to high speed injection is generally used to obtain a glossy surface.

Holding Pressure and Time: This is crucial for controlling shrinkage (sinking). Sufficient holding pressure is required to compensate for shrinkage.

Sample Evaluation and Adjustment:

Dimensional Measurement: Use a coordinate measuring machine (CMM) and a 2D image measuring instrument to check critical dimensions.

Appearance Inspection: Inspect for defects such as shrinkage, flash, air bubbles, and weld lines.

Functional Testing: Perform assembly, strength, and other related tests.

Engineering Confirmation and Sample Approval: Improved samples will be submitted to you for engineering verification and your approval.

Process Parameter Locking: The final optimized parameters will be recorded in the injection molding process condition table as the mass production standard.

Fourth Stage: Mass Production and Process Control - Ensuring Stability

Ensuring that every molded product meets the standard.

Molding Cycle: Mold Closure → Injection → Holding Pressure → Cooling → Mold Opening → Ejection → Part Removal (automatically completed by a robotic arm).

Statistical Process Control (SPC):

Key Process Parameter Monitoring: Real-time monitoring and recording of injection time, peak pressure, material temperature, etc., to ensure process stability.

First Article Inspection (FAI): A comprehensive inspection of the first product at the start of each shift or after mold change.

Regular Sampling Inspection: Regular inspection of product appearance and key dimensions.

Quality Control Chart: Monitoring the stability of key product dimensions to achieve predictive management.

Phase 5: Quality Assurance and Delivery - The Final Checkpoint

Final Inspection and Packaging:

100% Visual Inspection or AOI (Automated Optical Inspection): A complete visual inspection of all products is conducted.

Protective Packaging: PE bags, bubble wrap, and partitions are used for packaging to prevent scratches and contamination.

Outgoing Quality Control (OQC): The batch to be shipped is inspected according to AQL sampling standards to ensure overall batch quality.

Document Delivery: Necessary quality documents are provided with the shipment, such as the Outgoing Quality Control Report (OQC Report) and Certificate of Conformity (COC).

Mold Maintenance and Care: Regular maintenance, rust prevention, and replacement of vulnerable parts are performed on the molds to ensure long-term stable operation.

We are a customized abs plastic injection parts moulding manufacturer, providing high-quality customized abs plastic injection parts moulding manufacturing. As long as you want to customize/develop customized abs plastic injection parts moulding products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.

FAQ

Q1: Are you trading company or manufacturer ?

A: We are manufacturers.

Q2. When can I get the quotation?

A: We usually quote within 2 days after we get your inquiry.

If you are very urgent, please call us or tell us in your email so that we can quote for you first.

Q3. How long is the lead-time for mold?

A: It all depends on the products' size and complexity. Normally, the lead time is 25 days.

Q4. I have no 3D drawing, how should I start the new project?

A: You can supply us a molding sample, we will help you finish the 3D drawing design.

Q5. Before shipment, how to make sure the products quality?

A: If you don't come to our factory and also don't have the third party for inspection, we will be as your inspection worker.

We will supply you a video for production process detail include process report, products size structure and surface detail, packing detail and so on.

Q6. What is your payment terms?

A: Mold Payment: 40% deposit by T/T in advance, 30% second mold payment before sending out the first trial samples, 30% mold balance after you agree the final samples.

B:Production Payment: 50% deposit in advance, 50% before sending out the final goods.

Q7: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit for best quality products.

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
