Custom drone parts moulding

In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized custom drone parts moulding products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For custom drone parts moulding products, we can make corresponding plastic parts, which is mainly done through injection molds.

Customized injection molding of drone parts is a systematic engineering process from design to mass production, with the core lying in balancing performance, weight and cost. The complete process is shown in the following figure and can be summarized into six key stages, among which the early design and verification (DFM and mode flow analysis) are the core that determines success or failure.

Preliminary design: The key to success or failure

This stage determines the manufacturability and final performance of the product. You need to focus on the following points:

Follow the principles of Design for Manufacturability (DFM)

Uniform wall thickness: The ideal wall thickness is usually between 0.8mm and 1.5mm, which is conducive to filling and cooling and can effectively reduce defects such as warping and shrinkage. For load-bearing parts, strength can be enhanced by internal reinforcing ribs rather than simply increasing the wall thickness.

Optimized structure: Compared with the traditional carbon plate assembly method, the one-piece injection-molded shell can integrate wire troughs and interfaces, enhancing protection and assembly efficiency.

Matching the application environment: This is the decisive factor in material selection.

High strength/heat resistance: Glass fiber reinforced PEEK (polyetheretherketone) or PPS (polyphenylene sulfide) are available as options, which feature excellent mechanical properties and heat resistance.

Corrosion/Moisture resistance: PA66 (nylon 66) has excellent hydrolysis resistance and salt spray resistance.

Insulation: In scenarios such as power inspection, high-insulation engineering plastics like PEEK should be selected and a fully enclosed insulation design should be adopted.

Conduct Moldflow analysis

Before mold opening, simulation analysis must be conducted using software such as Moldflow. This can virtually verify the mold design, optimize the gate position and runner system, and predict and solve potential problems such as weld lines, cavitation, and warpage deformation, thereby significantly reducing the cost and risk of mold testing.

�� production execution: from mold trial to mass production

When the design is frozen, it enters the production stage:

Mold manufacturing and trial molding: Process molds based on the final design, and then conduct small-batch trial molding. Test molds are used for strict dimensional, assembly and functional tests. When necessary, process parameters (such as temperature, pressure, injection speed) need to be adjusted or even the mold needs to be modified.

Mass production and post-processing: Mass production begins after the trial mold is passed. After the parts are demolded, post-treatment processes such as removing the gate, polishing, painting or assembling metal inserts may be required.

Quality inspection: During mass production, continuous quality control is required. The methods include using calipers and coordinate measuring machines (CMM) for dimensional inspection, or conducting shape comparison through 3D scanning.

Core advice from �� for you

For the customization of drone parts, a more efficient and low-risk approach is to collaborate with professional injection molding service providers. They can offer a one-stop service ranging from design support (DFM), mold making, mold testing to mass production. Many service providers also offer 3D printing for rapid prototyping verification. If your order quantity is not large, you can also pay attention to the "shared factory" model within the industry. It is specifically designed to address the multi-specification and small-batch characteristics of the drone industry and can effectively lower the manufacturing threshold and costs for small and medium-sized enterprises

We are a custom drone parts moulding manufacturer, providing high-quality custom drone parts moulding manufacturing. As long as you want to customize/develop custom drone parts moulding products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.

FAQ

Q1: Are you trading company or manufacturer ?

A: We are manufacturers.

Q2. When can I get the quotation?

A: We usually quote within 2 days after we get your inquiry.

If you are very urgent, please call us or tell us in your email so that we can quote for you first.

Q3. How long is the lead-time for mold?

A: It all depends on the products' size and complexity. Normally, the lead time is 25 days.

Q4. I have no 3D drawing, how should I start the new project?

A: You can supply us a molding sample, we will help you finish the 3D drawing design.

Q5. Before shipment, how to make sure the products quality?

A: If you don't come to our factory and also don't have the third party for inspection, we will be as your inspection worker.

We will supply you a video for production process detail include process report, products size structure and surface detail, packing detail and so on.

Q6. What is your payment terms?

A: Mold Payment: 40% deposit by T/T in advance, 30% second mold payment before sending out the first trial samples, 30% mold balance after you agree the final samples.

B:Production Payment: 50% deposit in advance, 50% before sending out the final goods.

Q7: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit for best quality products.

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
