Injection Moulding With Metal Insert

In the field of precision structural component manufacturing, a single material often fails to meet the composite requirements of "high-strength connection+complex structural forming". Metal insert injection molding (commonly known as "insert injection molding") is a "plastic metal integration" process that precisely fixes prefabricated metal inserts (such as nuts, bolts, terminals) in a mold, and then injects molten plastic to wrap them, ultimately forming a "metal reinforced, plastic molded" composite product. This technology not only retains the core properties of high strength and high conductivity of metals, but also leverages the advantages of lightweight and complex structure of plastics, completely replacing the inefficient mode of traditional "injection molding before assembling metal parts". It is widely used in fields such as automobiles, electronics, and home appliances that require high connection strength and integration.

Metal insert injection molding refers to the injection molding process that uses prefabricated metal inserts (such as brass nuts, stainless steel bolts, copper terminals, etc., which need to be processed into specific shapes in advance) and thermoplastic materials (such as PA, POM, ABS, etc.) as raw materials, and through the process of "insert positioning → mold clamping → plastic injection → cold curing → product demolding", firmly combines metal inserts with plastic. Its core goal is to achieve "one-time molding of plastic structures+precise embedding of metal components" while meeting the functions of the product (such as threaded connection, conductivity, and load-bearing), eliminating the risk of gaps and looseness in traditional assembly, and improving production efficiency and product reliability.

P&M Injection Moulding With Metal Insert Introduction

1. Preliminary Preparation: Pre processing of Embedded Components and Debugging of Molds (Key Fundamentals)

Pre preparation directly affects the quality of subsequent molding, and special attention should be paid to the processing of inserts and the accuracy of molds.

Pre treatment of metal inserts:

Cleaning and degreasing: Metal inserts may have residual oil stains and iron filings during processing, which need to be thoroughly cleaned by ultrasonic cleaning (using neutral degreasing agent, temperature 50-60 ℃, time 5-10 minutes) or solvent wiping (such as alcohol) to avoid oil stains affecting the bonding between plastic and metal (oil stains can cause bubbles and delamination on the bonding surface);

Surface treatment (as needed): Based on the type of plastic and the requirements of the working conditions, surface treatment is carried out on the inserts, such as nickel plating on brass inserts (to improve corrosion resistance and bonding strength), passivation of stainless steel inserts (oxidation prevention), and galvanizing of iron inserts (rust prevention). After treatment, it is necessary to ensure that the surface is free of impurities and the roughness meets the standard;

Size screening: Use calipers or automated screening equipment to check the size of the insert (such as nut inner diameter, terminal thickness), remove out of tolerance products (size tolerance should be controlled within ± 0.03mm), and avoid positioning failure caused by inaccurate insert size;

2. Embedded positioning: Automated feeding and precise fixation (core process)

Embedded positioning is the "lifeline" of embedded injection molding, and positioning deviation can directly lead to product scrap. It is usually achieved through automated equipment:

3. Plastic injection: parameter control adapted to metal properties (key link)

The high thermal conductivity of metal inserts can alter the filling and cooling behavior of plastics, requiring targeted adjustment of injection molding parameters.

4. Pressure holding and cooling: Ensure tight bonding and dimensional stability (core guarantee)

Pressure maintenance and cooling need to balance the "plastic shrinkage compensation" and "metal thermal conductivity influence" to avoid gaps at the joint surface.

5. Demoulding and post-treatment: protect composite products and test key performance

Demoulding should avoid separation between the embedded parts and the plastic, and post-processing should focus on bonding quality and dimensional accuracy.

P&M Injection Moulding With Metal Insert(Specification)

P&M Injection Moulding With Metal Insert Feature And Application

1. Automotive field: high-strength components that can withstand harsh working conditions

The automotive industry is the core application scenario for metal insert injection molding, which needs to cope with harsh environments such as vibration, high and low temperatures, and oil pollution.

2. In the field of electronics and home appliances: high-precision connection and conductive integration

The field of electronics and home appliances requires "miniaturization, high integration, and low failure", and metal insert injection molding can achieve precise connection and functional integration.

3. Industrial and mechanical fields: load-bearing and wear-resistant composite components

In the field of industrial machinery, high load-bearing capacity, high wear resistance, and long service life are required. Metal injection molding can replace some metal components to achieve lightweight and cost optimization.

4. Medical equipment field: safety and precision composite components

Medical equipment needs to be "sterile, corrosion-resistant, and reliably connected", and metal insert injection molding can meet medical grade safety standards.

5. Consumer and smart home fields: components that balance hand feel and durability

Consumer and smart home products require "good hand feel, good appearance, and strong durability", and metal insert injection molding can enhance product texture and lifespan.
