Keyboard custom parts moulding

In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized keyboard custom parts moulding products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For keyboard custom parts moulding products, we can make corresponding plastic parts, which is mainly done through injection molds.

This is the stage of shaping the soul of the keyboard, far more than just drawing.

Core requirement communication

Layout and structure: Configuration (such as 65%, 75%, TKL), connection method (wired/three-mode), structure (Gasket mount, Top mount, etc.), these directly determine the internal structure design of the housing.

The goal of hand feel and sound adjustment: material selection (affecting sound), positioning plate design (affecting softness and hardness), all need to serve this purpose.

Appearance theme: Color scheme (Pantone color code), surface treatment (high gloss, matte, special coatings such as electrophoresis), theme elements (Logo, decorative strips).

Industrial Design and Structural Design

Exterior design: Complete the ID renderings and determine the styling language and texture.

Structural design: Disassemble the parts and design all the clips, screw columns, reinforcing ribs, positioning columns, battery compartments, etc. This is the stage that tests engineering capabilities the most, directly affecting the smoothness of assembly and structural strength.

DFM Analysis and Materials Science Selection

Keycap

Material: ABS (smooth to the touch, easy to oil) or PBT (wear-resistant, strong granular feel, heat-resistant).

Key points of DFM: The design of reinforcing ribs prevents deformation, the size of the chrysanthemum-shaped columns is precise, and the wall thickness is uniform.

Shell

Materials: ABS (easy to spray), PC (high strength and high transparency), nylon (high-end, silent, extremely high strength).

Key points of DFM: Prevent shrinkage and warping of large flat surfaces; Fit tolerance design of the snap; Reserve the thickness of the spray/electroplating film.

Positioning plate

Materials: PC (soft and elastic), POM (brittle), FR4 (fiberglass board, non-injection molded), steel/aluminum (non-injection molded).

Key points of DFM: Shaft hole position accuracy (within ±0.05mm), rigidity guarantee.

Phase Two: Precision Mold Manufacturing

Molds are at the core of determining the final quality and cost efficiency.

Keycap mold

Ultra-high precision and multi-cavity: Ten or even hundreds of cavities in one module. Process chrysanthemum-shaped columns using a precision EDM machine.

Character processing: Regular engraved characters need to be laser-engraved or chemically etched on molds. Side engraving requires precise processing on the side of the mold.

Shell mold

Large and complex molds: Usually, multiple sliders are required to handle side overhangs and interfaces.

Ultimate surface treatment: The cavity needs to be mirror-polished or finely textured (such as coarse sand or fine sand texture) to achieve the desired touch.

Mold flow analysis: It must be carried out on keycaps and housings to predict filling, optimize gates (such as the commonly used bottom center point gate for keycaps), and prevent warping.

Phase Three: Injection Molding and Secondary Processing

Key points of injection molding process

Material drying: PBT, nylon and other materials must be strictly dried.

High mold temperature: Especially for PBT keycaps and PC housings, high mold temperature can reduce internal stress, improve dimensional stability and surface texture.

Secondary processing (the soul)

Keycap

Laser-engraved characters: Characters are engraved on the injection-molded keycaps and then filled with ink.

Two-color molding: Using two-color molds to produce characters that never wear out, it is costly and of top quality.

UV printing: Used for complex patterns.

Shell

Spraying: matte, glossy, metallic paint, etc.

Electroplating/anodizing (if the substrate is ABS+ electroplated grade or metal).

Water transfer printing /IMD: Achieve complex patterns such as wood grain and carbon fiber.

Phase Four: Full-chain quality inspection and assembly verification

This is the final hurdle to ensure a "ready-to-use" experience, and the customized keyboard has strict requirements for this.

Dimensional accuracy inspection

Keycaps: Use a dedicated inspection tool to measure the tightness of the Daisy column and the gap between the keycaps.

The shell: Use a three-coordinate measuring instrument to check the position, flatness and shape and position tolerance of the installation column.

Positioning plate: Detects the positional accuracy of all shaft holes to ensure perfect alignment with the PCB.

Appearance and texture inspection

Under standard light sources, 100% inspect the color difference, defects and water outlet treatment marks of the housing and keycaps.

Functional assembly testing (crucial)

Trial assembly: Assemble the entire set including the housing, positioning plate, PCB, shaft body and keycap.

Test item

Structural stability: Whether there is any shaking or abnormal noise.

Key consistency: Whether all key positions are smooth and if there are any stuck keys.

Soft and bouncy feel (if it is a Gasket structure) : Whether it is uniform.

Three-mode connection: Wireless connection stability.

Phase Five: Packaging and Delivery

Protective packaging: Customized inner supports made of EVA/ sponge are used to prevent scratches on the high-gloss surface during transportation.

Documents: Provide product specification sheets and quality inspection reports.

We are a keyboard custom parts moulding manufacturer, providing high-quality keyboard custom parts moulding manufacturing. As long as you want to customize/develop keyboard custom parts moulding products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.

FAQ

Q1: Are you trading company or manufacturer ?

A: We are manufacturers.

Q2. When can I get the quotation?

A: We usually quote within 2 days after we get your inquiry.

If you are very urgent, please call us or tell us in your email so that we can quote for you first.

Q3. How long is the lead-time for mold?

A: It all depends on the products' size and complexity. Normally, the lead time is 25 days.

Q4. I have no 3D drawing, how should I start the new project?

A: You can supply us a molding sample, we will help you finish the 3D drawing design.

Q5. Before shipment, how to make sure the products quality?

A: If you don't come to our factory and also don't have the third party for inspection, we will be as your inspection worker.

We will supply you a video for production process detail include process report, products size structure and surface detail, packing detail and so on.

Q6. What is your payment terms?

A: Mold Payment: 40% deposit by T/T in advance, 30% second mold payment before sending out the first trial samples, 30% mold balance after you agree the final samples.

B:Production Payment: 50% deposit in advance, 50% before sending out the final goods.

Q7: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit for best quality products.

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
