Mould For Injection Electric Box

Mould for injection electric box is a precision tooling specifically designed for producing plastic enclosures such as electrical control boxes, junction boxes, and instrument cases through injection molding process. Its core function is to inject molten thermoplastic materials (such as ABS, PC, PP, etc.) into the mold cavity, and after cooling and solidification, obtain electrical box shell components with specific electrical protection structures, installation positioning accuracy and insulation performance.

Compared with traditional metal electrical box processing molds, injection electric box molds have the ability to form complex structures (such as internal reinforcing ribs, guide rails, sealing grooves) in one step, which can increase electrical box production efficiency by more than 300% and improve material utilization from 60% in metal processing to over 95%. These molds are widely used in industrial control, building electrical, new energy and other fields, and are key manufacturing equipment for achieving lightweight, insulated and integrated electrical equipment.

P&M Mould For Injection Electric Box Introduction

Production Process of Mould For Injection Electric Box

1. Mold Design Stage

(1) Product Analysis and DFM Report

Analyze the 3D model of the electrical box product and determine the forming difficulties (such as deep cavity structures and complex inverted buckles);

Produce DFM (Design for Manufacturability) report, propose suggestions for parting surface position, gate design, core pulling scheme, etc;

Conduct mold flow analysis, simulate filling, pressure holding, and cooling processes, and optimize process parameters.

(2) Structural Design

Using software such as UG and AutoCAD for mold 3D structure design, including cavity, core, guide column and sleeve, ejector mechanism, etc;

Design cooling and exhaust systems;

Select a standard mold frame, determine the mold size and weight.

(3) Design review and optimization

2. Mold Manufacturing Stage

(1) Mold frame processing

(2) Cavity core processing

(3) Heat treatment and surface treatment

(4) Component assembly

3. Trial Molding and Optimization Stage

(1) First trial mold

(2) Problem analysis and rectification

(3) Acceptance and delivery

P&M Mould For Injection Electric Box(Specification)

P&M Mould For Injection Electric Box Feature And Application

1. Industrial Control Field

Application products: PLC control cabinet, frequency conversion control cabinet, machine tool electrical box, etc;

Mold features: Large multi cavity mold, capable of forming deep cavity structures and complex internal installation guide rails; High surface accuracy of the mold cavity ensures the sealing of the box body;

Material adaptation: Suitable for ABS+15% GF material, the mold needs to withstand high injection pressure, and the mold cavity uses H13 hot work mold steel;

2. Building Electrical Field

Application products: lighting distribution box, strong current box, weak current box, etc;

Mold characteristics: Small and medium-sized molds, mostly designed with 1 mold and 4 cavities or 1 mold and 8 cavities, with high production efficiency; Capable of forming multiple installation holes and buckle structures;

Material adaptation: Suitable for PP or PC/ABS alloy materials, the mold cooling system is designed uniformly to ensure uniform wall thickness;

3. New Energy Field

Application products: charging pile shell, photovoltaic inverter box, energy storage battery box, etc;

Mold features: Large precision molds with the ability to form complex sealing structures and heat dissipation ribs; The surface of the mold cavity is treated with anti-corrosion to adapt to outdoor environments;

Material adaptation: Suitable for PC+20% GF material, the mold needs to withstand high injection pressure and temperature;

Special requirements: The mold must ensure the stability of the box size and meet the long-term outdoor use needs of new energy equipment.

4. Instrumentation Field

Application products: instrument casing, sensor junction box, data acquisition terminal casing, etc;

Mold features: Small precision molds with high precision requirements; Ability to form thin-walled structures and subtle features;

Material adaptation: Suitable for ABS or PC materials, the mold cavity is polished to a mirror finish to ensure that the product surface is flawless;

Customization Process
