Plastic car parts custom moulding

In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized plastic car parts custom moulding products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For plastic car parts custom moulding products, we can make corresponding plastic parts, which is mainly done through injection molds.

In-depth analysis of Core processes

Phase One: Requirements Analysis and Concurrent Engineering

This is the cornerstone of the project's success, precisely defining the characteristics of ABS.

Requirement input: Clearly define whether the part is an interior component (such as dashboard, door panel, emphasizing appearance, touch, and low odor), an exterior component (such as grille, rearview mirror housing, emphasizing weather resistance), or a functional component (such as bracket, emphasizing strength). The core requirements include dimensional accuracy, mechanical properties, heat and weather resistance (such as exposure to sunlight), flame retardancy (such as UL94), and VOC/ odor standards.

ABS Special Synchronous Project

DFM analysis: Focus on optimizing the uniformity of wall thickness of ABS parts (to prevent shrinkage), the draft Angle (to prevent scratches on high-gloss surfaces), the design of reinforcing ribs (thickness ≤ 60% of the main body wall thickness), and the planning of parting lines and gate positions.

Material grade selection: Automotive ABS is by no means a universal material. Please select according to your requirements: high impact resistance type, electroplating grade (including special adhesive layer), heat-resistant grade, low odor /VOC grade, etc. Suppliers must provide complete material certification (UL Yellow Card).

CAE mold flow analysis: Mandatory execution. Simulating the filling, pressure holding, cooling and warpage of ABS melt, accurately predicting the position of weld lines and cavitation risks, and providing a basis for optimizing the mold cooling system is the key to controlling deformation.

Phase Two: Mold Design and process Development

Molds and processes are the decisive links in the quality of ABS parts.

Mold design for ABS:

Hot runner system: Needle valve type hot runner is recommended to ensure balanced filling and reduce runner waste.

Temperature control system: Design an efficient conformal cooling waterway to ensure uniform mold temperature, which is crucial for achieving consistent appearance and dimensions.

Surface treatment: According to the appearance requirements, the cavity is subjected to mirror polishing (for high-gloss surfaces), etching (such as leather grain, wood grain) or fire pattern treatment.

ABS Special Process development

Material pretreatment: ABS must be strictly dehumidified and dried. It is usually dried at 80-85℃ for 3-4 hours; otherwise, the product will develop silver streaks and bubbles, and its mechanical properties will decline significantly.

Temperature control: A relatively high mold temperature (60-80℃) is adopted. High mold temperature is the key for ABS to achieve a high-gloss surface, reduce weld marks, and lower internal stress, thereby avoiding cracking during later spraying.

Injection and pressure holding: Medium to high-speed injection is adopted to ensure surface gloss. Through precise control of multi-stage pressure holding, shrinkage is eliminated, especially on the back of the tendons.

Phase Three: Mass production Control and Delivery

Ensure that every product meets the zero-defect requirements of the automotive industry.

SPC Statistical Process Control: Real-time monitoring and statistical analysis of key process parameters (such as injection time, peak pressure, material temperature) and critical product dimensions are carried out to achieve preventive quality control.

Full-chain traceability and delivery: Establish a complete traceability system from raw material batches, production time, equipment parameters to finished products. All appearance parts must undergo 100% full inspection and be packaged in scratch-resistant materials.

⚙️ ABS specific considerations in automotive applications

The influence and key points of features on the customization process

ABS, with its excellent adhesion to spraying and electroplating, is the preferred base material for automotive sprayed and electroplated parts (such as bright strips and signs). Special grades should be used and the dimensional changes caused by the coating thickness should be taken into account in the early design.

With excellent comprehensive mechanical properties, it is more rigid and hard than PP and has a lower cost than PC. It is an ideal choice for "appearation-structure" integrated parts such as instrument panels and grilles.

The demand for weather resistance improvement: Ordinary ABS is prone to yellowing and aging outdoors. When used for exterior decoration, it is necessary to select UV-resistant modified grades or solve the problem by adding UV stabilizers or surface coatings.

The heat distortion temperature of heat-resistant ABS is approximately 90-100℃. When used in high-temperature areas such as the periphery of the engine compartment, heat-resistant ABS or materials like PPA and PA should be selected.

✅ Key points of supplier evaluation (for ABS automotive parts)

When looking for qualified suppliers, it is recommended to focus on examining:

Material cognition: Can you clearly explain the differences and application scenarios of different ABS grades (such as high impact resistance, electroplating grade)? Are there any well-known raw material suppliers with stable cooperation (such as Chi Mei and LG)?

Process expertise: Does the workshop strictly implement the ABS drying process? Is high mold temperature production generally adopted to obtain high-quality surfaces?

Quality system: Has it passed the IATF 16949 certification? Are there any testing devices such as three-coordinate measuring machines, color difference meters, and gloss meters available? Is there any testing capability for the adhesion of spraying/electroplating and VOC?

Industry Experience: Are there any successful mass production cases of providing ABS interior/exterior parts for mainstream Oems or first-tier suppliers? It would be best to provide physical objects for texture assessment.

�� summary and action suggestions

The core of successfully customizing ABS automotive parts lies in "thoroughly understanding materials, precise design, and meticulous control". Suggestion

Investment front-end analysis: Do not skimp on DFM and CAE mold flow analysis. This is the most cost-effective investment to avoid repeated mold modifications, control deformation, and ensure appearance.

Clarify priorities: At the early stage of the project, confirm with the supplier whether the part prioritizes appearance (such as high-gloss trim strips) or functionality (such as structural brackets) to concentrate resources.

Making prototype samples: Before mold opening, functional prototypes are made through high-precision CNC or 3D printing to verify assembly, feel and design

We are a plastic car parts custom moulding manufacturer, providing high-quality plastic car parts custom moulding manufacturing. As long as you want to customize/develop plastic car parts custom moulding products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.

FAQ

Q1: Are you trading company or manufacturer ?

A: We are manufacturers.

Q2. When can I get the quotation?

A: We usually quote within 2 days after we get your inquiry.

If you are very urgent, please call us or tell us in your email so that we can quote for you first.

Q3. How long is the lead-time for mold?

A: It all depends on the products' size and complexity. Normally, the lead time is 25 days.

Q4. I have no 3D drawing, how should I start the new project?

A: You can supply us a molding sample, we will help you finish the 3D drawing design.

Q5. Before shipment, how to make sure the products quality?

A: If you don't come to our factory and also don't have the third party for inspection, we will be as your inspection worker.

We will supply you a video for production process detail include process report, products size structure and surface detail, packing detail and so on.

Q6. What is your payment terms?

A: Mold Payment: 40% deposit by T/T in advance, 30% second mold payment before sending out the first trial samples, 30% mold balance after you agree the final samples.

B:Production Payment: 50% deposit in advance, 50% before sending out the final goods.

Q7: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit for best quality products.

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
