Plastic side cover motorcycle spare parts moulding

In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized plastic side cover motorcycle spare parts moulding products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve our customers. For plastic side cover motorcycle spare parts moulding products, we can make corresponding plastic parts, which is mainly done through injection molds.

Motorcycle plastic side covers are exposed exterior components mounted on both sides of the vehicle body. They are subjected to prolonged outdoor UV exposure, rain, oil corrosion, impacts from road debris, high engine temperatures, and continuous vibration. As large-surface-area, thin-walled, curved parts, they demand exceptional standards regarding surface gloss, weather resistance, low-temperature impact resistance, dimensional accuracy, and minimal internal stress. Mainstream materials include weather-resistant ASA and ABS/PC alloys, while some budget models utilize talc-filled modified PP. The following sections outline key molding considerations—covering raw materials, molds, injection molding processes, post-processing, and defect control—in an article totaling approximately 1,500 words.

I. Raw Material Selection and Pre-treatment Molding Essentials

Material Matching and Regrind Control

High-end models use ASA for its UV resistance (preventing yellowing) and superior weatherability; mid-range models employ ABS/PC alloys for high toughness and resistance to cracking during thermal cycling; budget models use filled modified PP for cost-effectiveness and oil resistance.

As exterior components, side covers must be produced primarily from virgin resin. The reuse ratio of clean sprues and runners of the same material is capped at 8%, and regrind must be sieved to remove coarse particles. Mixing in recycled scrap from other materials is strictly prohibited, as contaminants cause surface color variations and reduced impact strength, leading to brittle failure upon impact.

Materials are blended with weather-resistant color masterbatches, UV-resistant masterbatches, and low-blooming, oil-resistant mold release agents to prevent "blooming" (surface haze) or whitening caused by prolonged oil contact. Flame-retardant and glass-fiber-reinforced materials must be mixed and stored separately from standard exterior-grade materials to prevent cross-contamination. Mixing should occur at low speeds (under 300 rpm) for 6–10 minutes; high-speed friction can degrade UV-resistant additives and shorten the component's outdoor service life.

Strict Standards for Drying and Dehumidification

ASA and ABS/PC are highly hygroscopic; trace amounts of moisture can form micro-bubbles within the plastic part. These bubbles can lead to large-scale paint delamination after coating and cause the part to crack along bubble sites when subjected to impact during vehicle operation. ASA is dried with hot air at 85°C for 4 hours; ABS/PC alloy is dried at 90°C for 5–6 hours, with moisture content controlled below 0.04%. Filled PP is dried at 60°C for 1 hour—specifically during the rainy season—to remove surface moisture. After drying, raw materials are conveyed to the machine via a sealed hopper to prevent re-absorption of workshop humidity or oil mist.

II. Side Cover Mold Design and Machine Processing Essentials

The side cover is a thin-walled component with a curved surface; while the general wall thickness is 1.8–2.3 mm, internal reinforcing ribs and mounting snap-fit posts reach thicknesses of 4–6 mm. Significant temperature differentials between thick and thin sections make the part prone to shrinkage and warping, potentially leading to inconsistent assembly gaps between the left and right covers. Consequently, the mold design prioritizes mirror polishing, symmetrical cooling, balanced venting, and balanced ejection.

Mold Steel Selection

S136 corrosion-resistant mirror-finish steel is selected for all aesthetic cavities; precision polishing ensures a surface free of pits or scratches, promoting uniform paint adhesion. Cavities for filled-PP side covers undergo nitriding treatment to withstand long-term abrasive wear from talc fillers. All internal and external corners feature radii of at least 1.5 mm to eliminate stress concentrations, preventing cracks caused by vibration or thermal cycling. Parting line machining precision is maintained at ≤0.01 mm to minimize fine flash, ensuring smooth assembly and preventing excessive gaps.

Balanced Cooling System (Key to Warping Control)

Given the side cover's pronounced curvature, the mold employs symmetrical cooling channels that follow the product's contour, ensuring a perfectly balanced layout across long/short sides and inner/outer surfaces. Thick-walled mounting posts incorporate internal spiral cooling cores to facilitate simultaneous, balanced heat dissipation, thereby reducing temperature differentials between thick and thin sections. Mold temperatures are controlled by zone: 55–65°C for ASA side covers, 70–80°C for ABS/PC, and 30–40°C for filled PP. If the PP mold temperature is too high, crystallization shrinkage increases, leading to dimensional deviations in the left and right side covers and uneven assembly gaps; if the temperature is too low, significant residual internal stress remains, causing the housing to warp or deform under fluctuating summer heat and winter cold.

Optimization of Venting and Balanced Ejection

Given the long melt flow path for the side covers, continuous, fine venting channels (0.012–0.015 mm deep) are cut at the ends of curved surfaces, along ribs, and at weld line locations to rapidly exhaust gases from melt decomposition, thereby preventing surface black spots and brittle cracking at weld lines. Inside the part, a combination of symmetrical multi-point ejector pins and flat ejector pads ensures uniform ejection force, preventing stress marks (whitening) or deformation on curved surfaces; independent small ejector blocks are added for snap-fits to prevent breakage that could lead to assembly gaps.

Mold Installation and Operation Standards

The single-cavity side cover mold is paired with a 400T–700T injection molding machine; clamping plates must be tightened evenly to withstand high-pressure injection and prevent large-scale flash caused by mold opening (mold breathing). Flow detectors are installed on cooling circuits to verify that each channel is free of blockages or leaks; low-pressure mold clamping protection is calibrated to trigger automatic mold opening if residual sprue or foreign objects are detected, protecting the mirror-finish cavity; the barrel must be thoroughly purged of residual incompatible plastics before production. The mold must be preheated for 30 minutes to stabilize the temperature before trial molding begins.

III. Key Points of Injection Molding Process Control

Core Process Strategy: Low-shear staged filling, two-stage low-pressure packing, and sufficient, balanced cooling to minimize internal molding stress and enhance outdoor weather resistance and crack resistance.

Precise Staged Barrel Temperature Control

ASA side covers: 170–200°C; nozzle temperature must not exceed 210°C (excessive heat decomposes UV-resistant additives, causing short-term yellowing during outdoor exposure).

ABS/PC side covers: 190–250°C; upper limit 260°C (excessive heat reduces low-temperature toughness, making parts prone to cracking upon impact in winter).

Filled PP side covers: 190–220°C; excessive temperatures cause powder precipitation, resulting in surface white spots or "blooming." Multi-stage Variable-speed Filling Process

The curved side cover utilizes a three-stage variable-speed filling process: low-speed buffering at the gate, rapid medium-to-high speed filling of the curved main body, and reduced speed for venting in the distal weld line area to minimize internal stress caused by molecular shear. The injection pressure ranges from 85 to 110 bar; excessively low pressure results in poor weld line fusion and potential fracture due to vehicle vibration, while excessively high pressure leads to increased flash, internal stress accumulation, and whitening or cracking upon contact with engine oil.

Two-stage Staged Holding Pressure

Due to the significant crystallization shrinkage of PP, a two-stage staged holding pressure process is required to compensate for shrinkage; conversely, ASA and ABS/PC exhibit lower shrinkage, so low-pressure, short-duration holding is employed. Holding times are set at 6–10 seconds for the thin-walled curved body and 12–18 seconds for the thick-walled mounting clips to eliminate sink marks at the clips and ribs. Holding pressure and material plasticization (metering) occur simultaneously to shorten the molding cycle.

We are a plastic side cover motorcycle spare parts moulding manufacturer, providing high-quality plastic side cover motorcycle spare parts moulding manufacturing. As long as you want to customize/develop plastic side cover motorcycle spare parts moulding products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.

FAQ

Q1: Are you trading company or manufacturer ?

A: We are manufacturers.

Q2. When can I get the quotation?

A: We usually quote within 2 days after we get your inquiry.

If you are very urgent, please call us or tell us in your email so that we can quote for you first.

Q3. How long is the lead-time for mold?

A: It all depends on the products' size and complexity. Normally, the lead time is 25 days.

Q4. I have no 3D drawing, how should I start the new project?

A: You can supply us a molding sample, we will help you finish the 3D drawing design.

Q5. Before shipment, how to make sure the products quality?

A: If you don't come to our factory and also don't have the third party for inspection, we will be as your inspection worker.

We will supply you a video for production process detail include process report, products size structure and surface detail, packing detail and so on.

Q6. What is your payment terms?

A: Mold Payment: 40% deposit by T/T in advance, 30% second mold payment before sending out the first trial samples, 30% mold balance after you agree the final samples.

B:Production Payment: 50% deposit in advance, 50% before sending out the final goods.

Q7: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit for best quality products.

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
